Schneider Electric K1B0 Series Push Button Switch, Slow Break, Front, 22 mm Cutout 690 V ac

RS Stock No.:: 347-072
หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:: K1B002A
ผู้ผลิต:: Schneider Electric

Schneider Electric K1B0 Series Push Button Switch, Slow Break, Front, 22 mm Cutout 690 V ac

ยอดรวมย่อย (1 ชิ้น)*

THB1,453.88

(ไม่รวมภาษีมูลค่าเพิ่ม)

THB1,555.65

(รวมภาษีมูลค่าเพิ่ม)

ส่งฟรีหากซื้อเกิน ฿2,500.00

มีในสต็อกของผู้ผลิต

พร้อมส่งจากวันที่ 05 มิถุนายน 2569

ต้องการสินค้าเพิ่มหรือไม่ ระบุจำนวนและคลิก ‘ตรวจสอบวันจัดส่ง’ เพื่อดูข้อมูลเพิ่มเติมเกี่ยวกับสต็อกสินค้าและการจัดส่ง

ชิ้น	ต่อหน่วย
1 +	THB1,453.88

*ตัวบ่งบอกราคา / price indicative

RS Stock No.:: 347-072
หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:: K1B002A
ผู้ผลิต:: Schneider Electric

คุณสมบัติ / Specifications

ข้อมูลทางเทคนิค / Technical Data Sheets

Legislation and Compliance

รายละเอียดสินค้า / Product Details

ค้นหาผลิตภัณฑ์ที่คล้ายกันโดยเลือกคุณลักษณะอย่างน้อยหนึ่งรายการ

เลือกทั้งหมด	คุณลักษณะ	ค่า
	Brand	Schneider Electric
	Product Type	Push Button Switch
	Switch Operation	Slow Break
	Illuminated	No
	Series	K1B0
	Panel Cutout Size	22 mm
	Mount Type	Front
	Terminal Type	Screw Clamp
	Contact AC Voltage	690V ac
	Minimum Operating Temperature	-25°C
	Maximum Operating Temperature	55°C
	Standards/Approvals	IEC 60947-5-1 for control circuit, IEC 60947-3 for power circuit, CENELEC EN 50013
	Length	45mm
	Width	49mm
	Switch Contact Current	12A
	Height	50mm

	เลือกทั้งหมด
	Brand Schneider Electric
	Product Type Push Button Switch
	Switch Operation Slow Break
	Illuminated No
	Series K1B0
	Panel Cutout Size 22 mm
	Mount Type Front
	Terminal Type Screw Clamp
	Contact AC Voltage 690V ac
	Minimum Operating Temperature -25°C
	Maximum Operating Temperature 55°C
	Standards/Approvals IEC 60947-5-1 for control circuit, IEC 60947-3 for power circuit, CENELEC EN 50013
	Length 45mm
	Width 49mm
	Switch Contact Current 12A
	Height 50mm

COO (Country of Origin):: CZ

Schneider Electric Harmony Series Push Button Switch, 22mm Panel Cut Out Diameter, 12A Contact Current Rating - K1B002A

This push button switch is an efficient control device designed for various industrial applications. With a panel cut-out diameter of 22mm, it features slow break operation and is front mounted for easy accessibility. Engineered by Schneider Electric, this product is suitable for high-voltage environments with a voltage rating of 690V AC and a contact current rating of 12A. It is constructed from Durable plastic, ensuring its resilience under various conditions.

Features & Benefits

• Designed for slow break operation, reducing electrical arcing
• Supports a high voltage rating of up to 690V AC
• Robust body MADE from plastic for longevity and durability
• Front mounting allows for straightforward installation in panels
• Utilises captive screw clamp terminals for secure connections

Applications

• Utilised in control panels for industrial machinery
• Ideal for automation systems that require reliable switching
• Appropriate for electrical distribution and control
• Suited for use in environments with extreme temperature variations

What are the advantages of the captive screw clamp design?

This design allows for easy and secure connection of wires, minimising the risk of loose connections that can lead to operational issues or failures.

What kind of environments is it suitable for?

It operates effectively in harsh environments, functioning well at temperatures between -25°C to +55°C, making it versatile for various industrial conditions.

How does slow break operation benefit the equipment?

Slow break operation prevents electrical arcing, reducing wear on contacts and prolonging the lifespan of the switch, thereby enhancing system reliability.

What current capacity does the switch support?

It supports a contact current rating of 12A, making it suitable for handling substantial electrical loads in industrial applications.

How does the design cater to ease of installation?

The front-mounted configuration simplifies the installation process, allowing for quick access when needing adjustments or replacements in panel settings.
