    Lascar PanelPilot , TFT Digital Panel Multi-Function Meter for Current, 74mm x 92mm

    RS Stock No.:
    777-6849
    หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:
    SGD 35-M420
    ผู้ผลิต / Manufacturer:
    Lascar
    Lascar
    ดูหมวดหมู่นี้
    สามารถสั่งจองล่วงหน้าได้
    Add to Basket
    Units

    ราคา / Price Each

    คือ THB6,468.53

    คุณจ่าย

    THB5,852.48

    (exc. VAT)

    THB6,262.15

    (inc. VAT)

    UnitsPer unit
    1 +THB5,852.48
    RS Stock No.:
    777-6849
    หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:
    SGD 35-M420
    ผู้ผลิต / Manufacturer:
    Lascar
    COO (Country of Origin):
    CN

    ข้อมูลทางเทคนิค / Technical Data Sheets


    Legislation and Compliance

    COO (Country of Origin):
    CN

    รายละเอียดสินค้า / Product Details

    3.5" Programmable TFT 4-20mA Loop Process Meter


    Lascar's SGD 35-M420 series is a 3.5" programmable process meter featuring two 4-20mA analogue inputs and alarm outputs with a smart graphics display-current loop indicator. This colour touch screen display is configured using the free PanelPilot M software for Windows, users can choose from an increasing number of voltmeter types that can be customised as per their needs. Choose from a number of configurations including bar-graphs, tank level, analogue styles, and trend graphs. The users can customise the colours, text labels, splash screen and input voltage scaling through the software and upload to the meter with the help of the USB connection.

    Once programming is complete, users can save all selections to the meter and computer, detach the unit and mount in their panel as they would a standard display.

    Features and Benefits


    3.5" colour TFT screen
    Use the free PanelPilot software, to setup and customise the display. Compatible with Windows 7, 8.1 and 10
    Programmable via the USB interface
    Simple panel mounting solution with screw terminal connection
    Operating voltage of 4V-30V d.c.
    Measures 4-20mA current loop
    Digital hold

    Applications


    Marine
    Test & Measurement
    Industrial

    Lascar's PanelPilot software is available for download for free from www.lascarelectronics.com/software/panelpilot-software
    Easy to install and use, the control software runs under Windows 7, 8.1 and 10.

    Certifications


    ANSI/ESD S20.20:2014
    BS EN 61340-5-1:2007


    คุณสมบัติ / Specifications

    คุณสมบัติValue
    Properties MeasuredCurrent
    Display TypeTFT
    Cutout Height74mm
    Cutout Width92mm
    Depth17.7mm
    Minimum Temperature0°C
    Maximum Temperature+40°C
    Measurement Range4 to 20mA
    Meter TypeDigital
    SeriesPanelPilot
