TRACOPOWER Switching Regulator, Through Hole, 1.8V dc Output Voltage, 4.6 → 36V dc Input Voltage, 2A Output
- RS Stock No.:
- 906-8471
- หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:
- TSR 2-2418
- ผู้ผลิต / Manufacturer:
- TRACOPOWER
รูปภาพประกอบสินค้าเป็นเพียงรูปภาพใกล้เคียงเท่านั้น กรุณาอ่านรายละเอียดสินค้า
ราคา / Price Each**
THB512.86
(ไม่รวมภาษีมูลค่าเพิ่ม)
THB548.76
(รวมภาษีมูลค่าเพิ่ม)
* วันที่จัดส่งอาจเปลี่ยนแปลงได้ตามจำนวนสินค้าที่คุณเลือกหรือที่อยู่จัดส่งของคุณ
ฟรี ค่าจัดส่งสำหรับการสั่งซื้อมากกว่า THB2,500.00 (ไม่รวมภาษี)
ชิ้น | ต่อหน่วย |
---|---|
1 - 2 | THB512.86 |
3 - 4 | THB500.03 |
5 + | THB492.32 |
**ตัวบ่งบอกราคา / price indicative
- RS Stock No.:
- 906-8471
- หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:
- TSR 2-2418
- ผู้ผลิต / Manufacturer:
- TRACOPOWER
เลือกทั้งหมด | คุณลักษณะ | ค่า |
---|---|---|
Brand | TRACOPOWER | |
Output Voltage | 1.8V dc | |
Output Current | 2A | |
Input Voltage | 4.6 → 36V dc | |
Mounting Type | Through Hole | |
Number of Outputs | 1 | |
Package | SIP | |
Efficiency | 82% | |
Ripple And Noise | 50mV Pk-Pk | |
Minimum Temperature | -40°C | |
Maximum Temperature | +85°C | |
Series | TSR 2 | |
Line Regulation | Maximum of 0.5% | |
MTBF | 13520000h | |
Rated Output Power | 2W | |
Power Signal Conversion Type | DC-DC | |
Depth | 10.1mm | |
Standards Met | IEC/EN 60950-1, MIL-STD-810F, UL 60950-1, UL 94 V-0 | |
Length | 14mm | |
Maximum Input Current | 1mA | |
Switching Frequency Range | 410kHz | |
Protection Features | Over Temperature Protection, Overload Protection, Short Circuit Protection | |
Weight | 2.6g | |
Load Regulation | Maximum of 1% | |
Width | 7.5mm | |
เลือกทั้งหมด | ||
---|---|---|
Brand TRACOPOWER | ||
Output Voltage 1.8V dc | ||
Output Current 2A | ||
Input Voltage 4.6 → 36V dc | ||
Mounting Type Through Hole | ||
Number of Outputs 1 | ||
Package SIP | ||
Efficiency 82% | ||
Ripple And Noise 50mV Pk-Pk | ||
Minimum Temperature -40°C | ||
Maximum Temperature +85°C | ||
Series TSR 2 | ||
Line Regulation Maximum of 0.5% | ||
MTBF 13520000h | ||
Rated Output Power 2W | ||
Power Signal Conversion Type DC-DC | ||
Depth 10.1mm | ||
Standards Met IEC/EN 60950-1, MIL-STD-810F, UL 60950-1, UL 94 V-0 | ||
Length 14mm | ||
Maximum Input Current 1mA | ||
Switching Frequency Range 410kHz | ||
Protection Features Over Temperature Protection, Overload Protection, Short Circuit Protection | ||
Weight 2.6g | ||
Load Regulation Maximum of 1% | ||
Width 7.5mm | ||
