TRACOPOWER Switching Regulator, Through Hole, 1.2V dc Output Voltage, 4.6 → 36V dc Input Voltage, 1A Output

The Tracopower TSR-1 series of step-down switching regulators are great replacement for linear regulators as they solve many power supply problems. These DC to DC converters are up to 96% more efficient with built-in capacitors and short circuit protection. Allowing full load operation up to +60°C ambient temperature without the need of any heat sink or forced cooling. The TSR-1 switching regulators provide other significant features over linear regulators. Providing better output accuracy (±2%), lower standby current of 2 mA and no requirement of external capacitors. The high efficiency and low standby power consumption makes these regulators an ideal solution for many battery powered applications.

Up to 96% efficiency
No heat-sink required
Pin compatible with LMxx linear regulators
SIP-package fits existing TO-220 footprint
Built in filter capacitors
Operation temperature range –40°C to +85°C
Short circuit protection
Wide input operating range
Excellent line / load regulation
Low standby current

This switching regulator provides precise voltage regulation for a range of electronic applications. With an output voltage of 1.2 V DC and a maximum current of 1 A, it delivers stable performance across an input range of 4.6 to 36 V DC. Its compact SIP 3 package, designed for through-hole mounting, is ideal for environments with limited space, such as in automation, electrical, and mechanical industries where effective power supply regulation is vital.

• High efficiency of 74% reduces energy loss
• Low ripple noise of 50 mV ensures clean output signals
• Wide input voltage range enhances versatility
• Compact design fits standard SIP 3 mounting
• Good line regulation maintains output stability
• Robust temperature range supports various operational conditions

• Powering microcontrollers in automation systems
• Suitable for communication devices that require precise voltage sources
• Ideal for industrial electronics needing effective power regulation
• Commonly used in medical devices where voltage stability is important
• Employed in sensitive measurement instruments requiring low noise

It accepts input voltages from 4.6 V to 36 V DC for optimal performance.

Higher efficiency lessens energy waste, leading to reduced operating costs and heat generation.

With an operational range of -40 to +85 °C, it can be used in various environments, including outdoor settings.

It is important to use the correct mounting techniques for through-hole installations to ensure performance.

The regulator maintains stable output under load changes, with low load regulation of ±0.6%.
