Sensata Crydom Solid State Relay, 5 A Load, PCB Mount, 660 V rms Load, 32 V dc Control
- RS Stock No.:
- 738-5575
- หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:
- MCXE480D5
- ผู้ผลิต:
- Sensata / Crydom
ไม่พร้อมจำหน่ายในตอนนี้
เราไม่ทราบว่าสินค้านี้จะกลับมาในสต็อกหรือไม่ RS ตั้งใจที่จะลบสินค้านี้ออกจากกลุ่มผลิตภัณฑ์ในเร็วๆ นี้
- RS Stock No.:
- 738-5575
- หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:
- MCXE480D5
- ผู้ผลิต:
- Sensata / Crydom
คุณสมบัติ / Specifications
ข้อมูลทางเทคนิค / Technical Data Sheets
Legislation and Compliance
รายละเอียดสินค้า / Product Details
ค้นหาผลิตภัณฑ์ที่คล้ายกันโดยเลือกคุณลักษณะอย่างน้อยหนึ่งรายการ
เลือกทั้งหมด | คุณลักษณะ | ค่า |
|---|---|---|
| Brand | Sensata / Crydom | |
| Maximum Load Current | 5 A | |
| Mounting Type | PCB Mount | |
| Maximum Load Voltage | 660 V rms | |
| Minimum Load Voltage | 48 V rms | |
| Maximum Control Voltage | 32 V dc | |
| Minimum Control Voltage | 15 V dc | |
| Switching Type | Zero Cross | |
| Control Voltage Range | 15 → 32 V dc | |
| Minimum Load Current | 0.06 A rms | |
| Terminal Type | Through Hole | |
| Contact Configuration | SPST | |
| Output Device | SCR | |
| Package Style | SIP | |
| Load Voltage Range | 48 → 660Vrms | |
| Maximum Turn On Time | 1/2 cycle | |
| Dimensions | 43.1 x 10.2 x 25.4mm | |
| Depth | 10.2mm | |
| Operating Temperature Range | -40 → +80°C | |
| Minimum Operating Temperature | -40°C | |
| Length | 43.1mm | |
| Off State Leakage Current | 0.1 mA rms | |
| Height | 25.4mm | |
| Maximum Operating Temperature | +80°C | |
| เลือกทั้งหมด | ||
|---|---|---|
Brand Sensata / Crydom | ||
Maximum Load Current 5 A | ||
Mounting Type PCB Mount | ||
Maximum Load Voltage 660 V rms | ||
Minimum Load Voltage 48 V rms | ||
Maximum Control Voltage 32 V dc | ||
Minimum Control Voltage 15 V dc | ||
Switching Type Zero Cross | ||
Control Voltage Range 15 → 32 V dc | ||
Minimum Load Current 0.06 A rms | ||
Terminal Type Through Hole | ||
Contact Configuration SPST | ||
Output Device SCR | ||
Package Style SIP | ||
Load Voltage Range 48 → 660Vrms | ||
Maximum Turn On Time 1/2 cycle | ||
Dimensions 43.1 x 10.2 x 25.4mm | ||
Depth 10.2mm | ||
Operating Temperature Range -40 → +80°C | ||
Minimum Operating Temperature -40°C | ||
Length 43.1mm | ||
Off State Leakage Current 0.1 mA rms | ||
Height 25.4mm | ||
Maximum Operating Temperature +80°C | ||
- COO (Country of Origin):
- MX
MCX-SIL SSR up to 5Aac
AC or DC controlled versions
Ultra high 1-cycle surge capability
Surge current peak: 250A
Input-Output capacitance: 10pF
SPST-NO configuration
Zero-cross switching where stated otherwise Random-fire
Operating temperature range: -40 to +80°C
Dimensions H25mm x W10.2mm x D43mm
Ultra high 1-cycle surge capability
Surge current peak: 250A
Input-Output capacitance: 10pF
SPST-NO configuration
Zero-cross switching where stated otherwise Random-fire
Operating temperature range: -40 to +80°C
Dimensions H25mm x W10.2mm x D43mm
Caution
Derating will limit the maximum load current at temperatures above 25°C
For these non-cancellable (NC), and non-returnable (NR) products, Terms and Conditions apply.
Approvals
UL
