Lapp Unitronic LiHCH Series Data Cable 25 Pairs 0.14 mm² 50 m Pebble Grey Sheath Low Smoke Zero Halogen (LSZH)
- RS Stock No.:
- 807-9174
- Distrelec หมายเลขบทความ:
- 304-36-402
- หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:
- 0038325
- ผู้ผลิต:
- Lapp
เพิ่มอีก 5 ชิ้นเพื่อประหยัดได้ 3%
ดูตัวเลือกการกำหนดราคาในการซื้อปริมาณมากยอดรวมย่อย (1 รีล รีลละ 50 เมตร)*
THB23,847.77
(ไม่รวมภาษีมูลค่าเพิ่ม)
THB25,517.11
(รวมภาษีมูลค่าเพิ่ม)
ส่งฟรีหากซื้อเกิน ฿2,500.00
- 2 ชิ้นพร้อมจัดส่งจากคลังสินค้าต่างประเทศ
ม้วน | ต่อม้วน | ต่อเมตร* | การประหยัด |
|---|---|---|---|
| 1 - 4 | THB23,847.77 | THB476.955 | - |
| 5 + | THB23,013.28 | THB460.266 | 3% |
*ตัวบ่งบอกราคา / price indicative
- RS Stock No.:
- 807-9174
- Distrelec หมายเลขบทความ:
- 304-36-402
- หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:
- 0038325
- ผู้ผลิต:
- Lapp
เลือกทั้งหมด | คุณลักษณะ | ค่า |
|---|---|---|
| Brand | Lapp | |
| Number of Pairs | 25 | |
| Product Type | Data Cable | |
| Cross Sectional Area | 0.14 mm² | |
| Cable Length | 50m | |
| Jacket Colour | Pebble Grey | |
| Outside Diameter | 12.7mm | |
| Minimum Operating Temperature | -40°C | |
| Conductor Type | Stranded | |
| Jacket Material | Low Smoke Zero Halogen (LSZH) | |
| Maximum Operating Temperature | 80°C | |
| Standards/Approvals | EU-Directive 2014/35/EU (Low Voltage Directive) and to EU-Directive 2011/65/EU (RoHS, Restriction of the use of certain hazardous substances) | |
| Screened/Unscreened | Screened | |
| Voltage | 250V | |
| Conductor Material | Bare Copper | |
| Fire Behaviour | Flame Retardant acc. to IEC 60332-1-2 resp. EN 60332-1-2 | |
| Series | Unitronic LiHCH | |
| เลือกทั้งหมด | ||
|---|---|---|
Brand Lapp | ||
Number of Pairs 25 | ||
Product Type Data Cable | ||
Cross Sectional Area 0.14 mm² | ||
Cable Length 50m | ||
Jacket Colour Pebble Grey | ||
Outside Diameter 12.7mm | ||
Minimum Operating Temperature -40°C | ||
Conductor Type Stranded | ||
Jacket Material Low Smoke Zero Halogen (LSZH) | ||
Maximum Operating Temperature 80°C | ||
Standards/Approvals EU-Directive 2014/35/EU (Low Voltage Directive) and to EU-Directive 2011/65/EU (RoHS, Restriction of the use of certain hazardous substances) | ||
Screened/Unscreened Screened | ||
Voltage 250V | ||
Conductor Material Bare Copper | ||
Fire Behaviour Flame Retardant acc. to IEC 60332-1-2 resp. EN 60332-1-2 | ||
Series Unitronic LiHCH | ||
- COO (Country of Origin):
- DE
LAPP Data Cable, 1.2kV Test Voltage, Copper Conductors - UNITRONIC LiHCH (TP)Series - 0038325
Features & Benefits
Applications
How flexible is this data cable?
