Lapp Multicore Data Cable, 0.5 mm², 8 Cores, 20 AWG, Screened, 100m, Grey Sheath
- RS Stock No.:
- 491-8876
- หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:
- 0034608
- ผู้ผลิต / Manufacturer:
- Lapp
5 มีของพร้อมจัดส่งภายใน (In stock for delivery within) 4-6 วันทำการ (working days)
ราคา / Price 1 Reel of 100 Metre(s)
THB17,061.53
(ไม่รวมภาษีมูลค่าเพิ่ม)
THB18,255.84
(รวมภาษีมูลค่าเพิ่ม)
ม้วน | ต่อม้วน | ต่อเมตร* |
---|---|---|
1 - 10 | THB17,061.53 | THB170.615 |
11 + | THB16,742.57 | THB167.426 |
*ตัวบ่งบอกราคา / price indicative
- RS Stock No.:
- 491-8876
- หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:
- 0034608
- ผู้ผลิต / Manufacturer:
- Lapp
ข้อมูลทางเทคนิค / Technical Data Sheets
Legislation and Compliance
- COO (Country of Origin):
- DE
รายละเอียดสินค้า / Product Details
LAPP Grey Screened Control Cable, 100m Length, 8 Cores - UNITRONIC Series - 0034608
Ensure the reliable communication of signals between your devices with this LiYCY control cable from LAPP. It has copper conductor material to provide high conductivity and efficiently transmit data over both short and long distances. Thanks to its multi-core design, you can bend and flex this cable to meet your application's needs without any loss of performance. A tinned copper braid screen shields the cable from electromagnetic interference, so there's no need to worry about disruption from nearby mobile networks and heavy machinery.
Features & Benefits
• Protected by a flame-retardant PVC sheath, helping to keep data connections safe in the event of a fire
• Features a non-wicking filler material, meaning the cable resists corrosion in humid indoor conditions
• Sold in a 100m length reel that can be cut to meet the needs of your application
• Insulating mylar bedding minimises energy loss through current leakage to ensure your data transmits reliably
• Features a non-wicking filler material, meaning the cable resists corrosion in humid indoor conditions
• Sold in a 100m length reel that can be cut to meet the needs of your application
• Insulating mylar bedding minimises energy loss through current leakage to ensure your data transmits reliably
Applications
• Specialised military vehicles
• AC power supply management
• Mining industry
• AC power supply management
• Mining industry
How can I identify the different conductor cores in this multi-core control cable?
The cores in this control cable are colour-coded for easy identification. This reduces the time spent on initial installation and future maintenance.
คุณสมบัติ / Specifications
คุณสมบัติ | Value |
---|---|
Cross Sectional Area | 0.5 mm² |
Number of Cores | 8 |
American Wire Gauge | 20 AWG |
Screened/Unscreened | Screened |
Length | 100m |
Shield Type | Tinned Copper Braid |
Sheath Colour | Grey |
CPR Certification | Eca |
Cable Type | LiYCY |
Outer Diameter | 8.7mm |
Outer Sheath Material | PVC |
Cable Shape | Multicore |
Series | UNITRONIC LiYCY |
Fire Behaviour | Flame Retardant |
Minimum Operating Temperature | -40°C |
Standards Met | CE |
Shielded/Unshielded | Shielded |
Maximum Operating Temperature | +80°C |
Voltage Rating | 500 V |
Core Strands | 16/0.20 mm |
