Crouzet Syr-Line Series Panel Mount Timer Relay, 24 → 240V ac/dc, 2-Contact, 0.001 → 9.999 s, 0.01

Brand

Crouzet

Supply Voltage

24 → 240V ac/dc

Mounting Type

Panel Mount

Mode of Operation

Recycler (Off Start), Recycler (On Start), Summation Time Relay, Symmetrical Flashing (Off Start), Symmetrical Flashing (On Start), Timing after Pulse of Control Contact, Total memory One Delay)

Time Range

0.001 → 9.999 s, 0.01 → 99.99 s, 0.1 → 999.9 min, 0.1 → 999.9 s, 0.1 → 999.9 h, 1 min → 99 h 59 min, 1 s → 99 min 59 s, 1 → 9999 h, 1 → 9999 s, 1 → 9999min

Number of Contacts

2

Number of Timer Functions

Multi Function

Contact Configuration

DPDT

Time Increment

Hours, Minutes, Seconds

Maximum Current

10A

Maximum Voltage

240V ac/dc

Terminal Type

11-Pin Connector

Switch Configuration

SPDT

Minimum Voltage

24V ac/dc

Power Supply

External

Width

48mm

Series

Syr-Line

Maximum Operating Temperature

+60°C

Length

48mm

Minimum Current

8A

Depth

68mm

Minimum Operating Temperature

-10°C
