Finder 38 Solid State Interface Relay 400V DIN Rail Cage Clamp
- RS Stock No.:
- 434-1399
- หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:
- 38.91.7.024.9024
- ผู้ผลิต:
- Finder
รับส่วนลดสำหรับการซื้อจำนวนมาก
เพิ่มอีก 15 ชิ้นเพื่อประหยัดได้ THB426.60
ดูตัวเลือกการกำหนดราคาในการซื้อปริมาณมากยอดรวมย่อย (1 ชิ้น)*
THB1,422.43
(ไม่รวมภาษีมูลค่าเพิ่ม)
THB1,522.00
(รวมภาษีมูลค่าเพิ่ม)
ส่งฟรีหากซื้อเกิน ฿2,500.00
มีในสต็อก
- เพิ่มอีก 53 ชิ้นจะส่งได้หลังจากวันที่ 23 พฤศจิกายน 2569 ไปอีกประมาณ 7 วันทำการ
ต้องการสินค้าเพิ่มหรือไม่ ระบุจำนวนและคลิก ‘ตรวจสอบวันจัดส่ง’ เพื่อดูข้อมูลเพิ่มเติมเกี่ยวกับสต็อกสินค้าและการจัดส่ง
ชิ้น | ต่อหน่วย | การประหยัด |
|---|---|---|
| 1 - 14 | THB1,422.43 | - |
| 15 - 74 | THB1,393.99 | THB426.60 |
| 75 + | THB1,147.26 | THB20,637.75 |
*ตัวบ่งบอกราคา / price indicative
- RS Stock No.:
- 434-1399
- หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:
- 38.91.7.024.9024
- ผู้ผลิต:
- Finder
คุณสมบัติ / Specifications
ข้อมูลทางเทคนิค / Technical Data Sheets
Legislation and Compliance
รายละเอียดสินค้า / Product Details
ค้นหาผลิตภัณฑ์ที่คล้ายกันโดยเลือกคุณลักษณะอย่างน้อยหนึ่งรายการ
เลือกทั้งหมด | คุณลักษณะ | ค่า |
|---|---|---|
| Brand | Finder | |
| Series | 38 | |
| Product Type | Solid State Interface Relay | |
| Maximum Control Voltage | 30V | |
| Maximum Operating Temperature | 55°C | |
| Switching Voltage | 400V | |
| Minimum Operating Temperature | -20°C | |
| Mount Type | DIN Rail | |
| Switching Current | 100mA, 16mA | |
| Terminal Type | Cage Clamp | |
| Output Type | Solid State Relay | |
| Isolation Voltage | 4kV | |
| Standards/Approvals | CE, EAC | |
| Length | 6.2mm | |
| Depth | 76mm | |
| Width | 14mm | |
| เลือกทั้งหมด | ||
|---|---|---|
Brand Finder | ||
Series 38 | ||
Product Type Solid State Interface Relay | ||
Maximum Control Voltage 30V | ||
Maximum Operating Temperature 55°C | ||
Switching Voltage 400V | ||
Minimum Operating Temperature -20°C | ||
Mount Type DIN Rail | ||
Switching Current 100mA, 16mA | ||
Terminal Type Cage Clamp | ||
Output Type Solid State Relay | ||
Isolation Voltage 4kV | ||
Standards/Approvals CE, EAC | ||
Length 6.2mm | ||
Depth 76mm | ||
Width 14mm | ||
- COO (Country of Origin):
- IT
Finder Series 38 Solid State Interface Relay, Screwless Terminal, 0.2ms Maximum Turn On Time - 38.91.7.024.9024
This solid-state interface relay is suitable for various automation applications, providing dependable operation within a compact design. With dimensions of 93.6x6.2x73.7mm, it features a maximum control voltage of 30V and a maximum load current of 2A. The SPST-NO configuration enables efficient performance for specific switching tasks, making it a useful component in control systems.
Features & Benefits
• Silent operation minimises noise in sensitive environments
• High-speed switching allows rapid response
• Low off-state leakage current enhances energy efficiency
• Flexible control voltage range increases compatibility
• Rail mount design facilitates installation and optimises space usage
• Integral coil indication confirms proper functioning
Applications
• Utilised in electromechanical systems interfacing
• Effective in HVAC control systems
• Commonly employed in industrial equipment
• Applicable in switch-mode power supplies
Can it handle both DC and AC load requirements?
Yes, this relay is compatible with both DC and AC loads.
Will it function in extreme temperatures?
It operates effectively between -20°C and +55°C.
Is it suitable for low-powered applications?
Yes, it manages minimum load currents from 1mA.
Can it be easily installed on a rail?
Yes, it features a design for straightforward rail mounting.
Is the relay's lifespan lengthy under normal use?
Yes, its long electrical life is designed for demanding applications.
