คุณสมบัติ / Specifications

ข้อมูลทางเทคนิค / Technical Data Sheets

Legislation and Compliance

รายละเอียดสินค้า / Product Details

ค้นหาผลิตภัณฑ์ที่คล้ายกันโดยเลือกคุณลักษณะอย่างน้อยหนึ่งรายการ

เลือกทั้งหมด	คุณลักษณะ	ค่า
	Brand	ITW Switches
	Actuator Colour	White
	Switch Operation	Latching
	Product Type	Push Button Switch
	Illuminated	Yes
	Panel Cutout Size	19.56 mm
	Series	H48M
	Mount Type	Panel
	Contact Configuration	SPDT
	Terminal Type	Solder
	LED Colour	Red
	IP Rating	IP67
	Minimum Operating Temperature	-25°C
	Contact AC Voltage	250V
	Contact DC Voltage	28V
	Actuator Style	Round
	Maximum Operating Temperature	65°C
	Switch Configuration	On-Off
	Switch Contact Current	10 A
	Standards/Approvals	CSA, UL

	เลือกทั้งหมด
	Brand ITW Switches
	Actuator Colour White
	Switch Operation Latching
	Product Type Push Button Switch
	Illuminated Yes
	Panel Cutout Size 19.56 mm
	Series H48M
	Mount Type Panel
	Contact Configuration SPDT
	Terminal Type Solder
	LED Colour Red
	IP Rating IP67
	Minimum Operating Temperature -25°C
	Contact AC Voltage 250V
	Contact DC Voltage 28V
	Actuator Style Round
	Maximum Operating Temperature 65°C
	Switch Configuration On-Off
	Switch Contact Current 10 A
	Standards/Approvals CSA, UL

Series_H48M Datasheet

COO (Country of Origin):: TW

ITW H48M Series Stainless Steel Indicator

The ITW H48M Series of rugged stainless steel electromechanical pushbuttons are offered in both momentary & latching operation. The H48M series also offers spot & ring illumination options, to accompany the standard plain actuator. The series provides a reliable and robust switch solution to a wide range of applications, such as security, food processing & medical installations.

The H48M series have been designed to easily mount into panels of a thickness range of 0.5 mm to 4.5 mm. Frontal sealing offers IP67 rating and is achieved by an o-ring fitted around the body.

Features and Benefits

Electro-mechanical operation.

Premium stainless steel constructed housing.

Momentary or latching operation.

Panel sealing up to IP67 rating.

Plain, centre spot & ring illumination options.

LED options available.

Typical Applications include:

External control equipment.

Industrial machinery.

Security equipment.

Medical equipment.

Food processing.

Mass transit and lift trucks.

ITW Switches H48M Series Illuminated Push Button Switch, Latching, Panel, 19.56 mm Cutout, SPDT, Red LED, IP67, 28 V

ITW H48M Series Stainless Steel Indicator
