Omron Plug In Power Relay, 24V dc Coil, 3A Switching Current, 4PDT
- RS Stock No.:
- 186-4178
- หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:
- MY4N-GS DC24
- ผู้ผลิต:
- Omron
ไม่พร้อมจำหน่าย
RS จะไม่สต็อกสินค้านี้อีกต่อไป
ตัวเลือก
สินค้านี้ไม่มีจำหน่ายในขณะนี้ ลองดูสินค้าอื่นที่เราแนะนำ
Each
THB459.95
(ไม่รวมภาษีมูลค่าเพิ่ม)
THB492.15
(รวมภาษีมูลค่าเพิ่ม)
- RS Stock No.:
- 186-4178
- หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:
- MY4N-GS DC24
- ผู้ผลิต:
- Omron
คุณสมบัติ / Specifications
ข้อมูลทางเทคนิค / Technical Data Sheets
Legislation and Compliance
รายละเอียดสินค้า / Product Details
ค้นหาผลิตภัณฑ์ที่คล้ายกันโดยเลือกคุณลักษณะอย่างน้อยหนึ่งรายการ
เลือกทั้งหมด | คุณลักษณะ | ค่า |
|---|---|---|
| Brand | Omron | |
| Coil Voltage | 24V dc | |
| Contact Configuration | 4PDT | |
| Mounting Type | Plug In | |
| Switching Current | 3A | |
| Number of Poles | 4 | |
| Latching | No | |
| Series | MY | |
| Terminal Type | Plug In | |
| Maximum Switching Voltage AC | 250V ac | |
| Maximum Switching Voltage DC | 220V dc | |
| Maximum Switching Current AC | 3 A | |
| Maximum Switching Current DC | 3 A | |
| Length | 28mm | |
| Coil Resistance | 662Ω | |
| Depth | 21.5mm | |
| Life | 50000000 cycles | |
| Isolation Coil To Contact | 2kV ac | |
| Maximum Operating Temperature | +70°C | |
| Minimum Operating Temperature | -40°C | |
| Height | 36mm | |
| Maximum Switching Power AC | 660VA | |
| Maximum Switching Power DC | 72 W | |
| Application | General Purpose | |
| เลือกทั้งหมด | ||
|---|---|---|
Brand Omron | ||
Coil Voltage 24V dc | ||
Contact Configuration 4PDT | ||
Mounting Type Plug In | ||
Switching Current 3A | ||
Number of Poles 4 | ||
Latching No | ||
Series MY | ||
Terminal Type Plug In | ||
Maximum Switching Voltage AC 250V ac | ||
Maximum Switching Voltage DC 220V dc | ||
Maximum Switching Current AC 3 A | ||
Maximum Switching Current DC 3 A | ||
Length 28mm | ||
Coil Resistance 662Ω | ||
Depth 21.5mm | ||
Life 50000000 cycles | ||
Isolation Coil To Contact 2kV ac | ||
Maximum Operating Temperature +70°C | ||
Minimum Operating Temperature -40°C | ||
Height 36mm | ||
Maximum Switching Power AC 660VA | ||
Maximum Switching Power DC 72 W | ||
Application General Purpose | ||
- COO (Country of Origin):
- CN
When 1864178 is no longer for sale, please see RS article 2711947 for the updated version in the new range of relays from Omron.
MY-GS - Miniature Power Relays Mechanical indicators added as a standard feature to our best-selling MY General-purpose relays.
MY-GS the last addition to MY family: produced by a complete automated factory
Reduces wiring work by 60% when combined with the PYF-PU Push-In Plus Socket (according to actual OMRON measurements).
The Printing on the coil tape indicates the operating coil specification
Mechanical operation indicators are a standard feature on all models
Mechanical indicators are a standard feature on all models to easily check the contact status.
MY-GS is suitable for application which need a reliable relay, the standard model is frequently seen in packaging machine for the food and beverage industry
Reduces wiring work by 60% when combined with the PYF-PU Push-In Plus Socket (according to actual OMRON measurements).
The Printing on the coil tape indicates the operating coil specification
Mechanical operation indicators are a standard feature on all models
Mechanical indicators are a standard feature on all models to easily check the contact status.
MY-GS is suitable for application which need a reliable relay, the standard model is frequently seen in packaging machine for the food and beverage industry
Note
This product is scheduled for discontinuation. Please refer to the attached Discontinuation notice for further details.
