Infineon EVAL-M3-TS6-665PN 3-Phase Inverter for half bridge gate driver IRS2890DS, IGBT H5 IKB20N65EH5, IKD06N65ET6,

The Infineon three-phase inverter power stage with half-bridge driver, single low-side driver and IGBT H5 uses PFC integration discrete IGBT and Gate driver for motor drives application. In combination with control-boards equipped with the M3 30pin interface connector, like EVAL-M3-102T and EVAL-M3-188. It features and demonstrates Infineon’s discrete technology for motor drives. The evaluation board EVAL-M3-TS6-665PN was developed to support customers during their first steps designing applications with discrete IGBTs and gate drivers.

Power Factor Correction
Current sensing with single shunt
Auxiliary power supply with 15 V, 3.3 V
Thermistor output
Measurement test-points compatible to standard oscilloscope probes
On board EMI filter
Overcurrent protection
Sensing of DC-link voltage
