Microchip, 8bit PIC, PIC18F Microcontroller, 64MHz, 32 kB Flash, 28-Pin QFN
- RS Stock No.:
- 177-9768
- หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:
- PIC18F25K80T-I/MM
- ผู้ผลิต:
- Microchip
ยอดรวมย่อย (1 แพ็ค แพ็คละ 5 ชิ้น)*
THB616.27
(ไม่รวมภาษีมูลค่าเพิ่ม)
THB659.41
(รวมภาษีมูลค่าเพิ่ม)
ส่งฟรีหากซื้อเกิน ฿2,500.00
- 6,390 ชิ้นพร้อมจัดส่งจากคลังสินค้าต่างประเทศ
ชิ้น | ต่อหน่วย | ต่อแพ็ค* |
|---|---|---|
| 5 - 395 | THB123.254 | THB616.27 |
| 400 - 795 | THB120.174 | THB600.87 |
| 800 + | THB118.324 | THB591.62 |
*ตัวบ่งบอกราคา / price indicative
- RS Stock No.:
- 177-9768
- หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:
- PIC18F25K80T-I/MM
- ผู้ผลิต:
- Microchip
เลือกทั้งหมด | คุณลักษณะ | ค่า |
|---|---|---|
| Brand | Microchip | |
| Family Name | PIC18F | |
| Package Type | QFN | |
| Mounting Type | Surface Mount | |
| Pin Count | 28 | |
| Device Core | PIC | |
| Data Bus Width | 8bit | |
| Program Memory Size | 32 kB | |
| Maximum Frequency | 64MHz | |
| RAM Size | 3.648 kB | |
| USB Channels | 0 | |
| Number of PWM Units | 1 x 16 bit | |
| Number of SPI Channels | 1 | |
| Number of UART Channels | 2 | |
| Typical Operating Supply Voltage | 5 (Maximum) V | |
| Number of USART Channels | 2 | |
| Number of I2C Channels | 1 | |
| Number of CAN Channels | 1 | |
| Minimum Operating Temperature | -40 °C | |
| Number of ADC Units | 1 | |
| Instruction Set Architecture | Harvard | |
| Automotive Standard | AEC-Q100 | |
| Maximum Operating Temperature | +85 °C | |
| ADCs | 8 x 12 bit | |
| Length | 6mm | |
| Pulse Width Modulation | 1 (4 x 16 bit) | |
| Maximum Number of Ethernet Channels | 0 | |
| Height | 0.95mm | |
| Number of LIN Channels | 0 | |
| Number of Ethernet Channels | 0 | |
| Number of PCI Channels | 0 | |
| Program Memory Type | Flash | |
| Dimensions | 6 x 6 x 0.95mm | |
| Width | 6mm | |
| Data Rate | 16Mbit/s | |
| เลือกทั้งหมด | ||
|---|---|---|
Brand Microchip | ||
Family Name PIC18F | ||
Package Type QFN | ||
Mounting Type Surface Mount | ||
Pin Count 28 | ||
Device Core PIC | ||
Data Bus Width 8bit | ||
Program Memory Size 32 kB | ||
Maximum Frequency 64MHz | ||
RAM Size 3.648 kB | ||
USB Channels 0 | ||
Number of PWM Units 1 x 16 bit | ||
Number of SPI Channels 1 | ||
Number of UART Channels 2 | ||
Typical Operating Supply Voltage 5 (Maximum) V | ||
Number of USART Channels 2 | ||
Number of I2C Channels 1 | ||
Number of CAN Channels 1 | ||
Minimum Operating Temperature -40 °C | ||
Number of ADC Units 1 | ||
Instruction Set Architecture Harvard | ||
Automotive Standard AEC-Q100 | ||
Maximum Operating Temperature +85 °C | ||
ADCs 8 x 12 bit | ||
Length 6mm | ||
Pulse Width Modulation 1 (4 x 16 bit) | ||
Maximum Number of Ethernet Channels 0 | ||
Height 0.95mm | ||
Number of LIN Channels 0 | ||
Number of Ethernet Channels 0 | ||
Number of PCI Channels 0 | ||
Program Memory Type Flash | ||
Dimensions 6 x 6 x 0.95mm | ||
Width 6mm | ||
Data Rate 16Mbit/s | ||
- COO (Country of Origin):
- TH
300nA Watch Dog Timer operation in Sleep modes
Integrated ECAN™ conforming to CAN 2.0B active specification
Extreme Low Power Sleep mode ideal for battery applications
Operating voltage 1.8V – 5.5V
Charge Time Measurement Unit (CTMU) supports Touch sensing and advanced sensing applications
Two analog comparators
Self programming Flash supports 10k erase/write cycles & 20 years retention
For these non-cancellable (NC), and non-returnable (NR) products, Terms and Conditions apply.
