Intelligent LED Solutions ILH-LC01-TRGR-SC201-WIR200. LUXEON C LED Array 1-LEDs Green LED
- RS Stock No.:
- 150-1910
- หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:
- ILH-LC01-TRGR-SC201-WIR200.
- ผู้ผลิต:
- Intelligent LED Solutions
มีส่วนลดเมื่อซื้อจำนวนมาก
ดูตัวเลือกการกำหนดราคาในการซื้อปริมาณมากยอดรวมย่อย (1 ชิ้น)*
THB447.32
(ไม่รวมภาษีมูลค่าเพิ่ม)
THB478.63
(รวมภาษีมูลค่าเพิ่ม)
ส่งฟรีหากซื้อเกิน ฿2,500.00
สต็อกสุดท้ายของ RS
- 3 ชิ้นสุดท้ายพร้อมจัดส่งจากคลังสินค้าต่างประเทศ
ชิ้น | ต่อหน่วย |
|---|---|
| 1 - 4 | THB447.32 |
| 5 - 9 | THB429.43 |
| 10 - 24 | THB411.53 |
| 25 + | THB402.57 |
*ตัวบ่งบอกราคา / price indicative
- RS Stock No.:
- 150-1910
- หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:
- ILH-LC01-TRGR-SC201-WIR200.
- ผู้ผลิต:
- Intelligent LED Solutions
คุณสมบัติ / Specifications
ข้อมูลทางเทคนิค / Technical Data Sheets
Legislation and Compliance
รายละเอียดสินค้า / Product Details
ค้นหาผลิตภัณฑ์ที่คล้ายกันโดยเลือกคุณลักษณะอย่างน้อยหนึ่งรายการ
เลือกทั้งหมด | คุณลักษณะ | ค่า |
|---|---|---|
| Brand | Intelligent LED Solutions | |
| Number of LEDs | 1 | |
| Product Type | LED Array | |
| LED Colour | Green | |
| Current | 700mA | |
| Typical Luminous Flux | 90lm | |
| Outside Diameter | 20mm | |
| Connection Type | Solder | |
| Onboard Driver | Yes | |
| LED Voltage | 2.55V | |
| Standards/Approvals | RoHS Compliant | |
| Series | LUXEON C | |
| Output Type | Constant Current | |
| Secondary Optics Included | Yes | |
| Automotive Standard | No | |
| Power Dissipation | 0.89W | |
| เลือกทั้งหมด | ||
|---|---|---|
Brand Intelligent LED Solutions | ||
Number of LEDs 1 | ||
Product Type LED Array | ||
LED Colour Green | ||
Current 700mA | ||
Typical Luminous Flux 90lm | ||
Outside Diameter 20mm | ||
Connection Type Solder | ||
Onboard Driver Yes | ||
LED Voltage 2.55V | ||
Standards/Approvals RoHS Compliant | ||
Series LUXEON C | ||
Output Type Constant Current | ||
Secondary Optics Included Yes | ||
Automotive Standard No | ||
Power Dissipation 0.89W | ||
- COO (Country of Origin):
- GB
LUXEON PowerStar LED Arrays
This range of LUXEON C PowerStars from Intelligent LED Solutions (ILS), feature 1 LUXEON C LED from LUMILEDS. The high-power LED offers high reliability and efficiency in a range of applications. LUXEON PowerStars are compact, powerful LED light sources built on aluminium substrates for optimal thermal management. With 200 mm wires as standard, PowerStar modules enable you to get up and running quickly and easily. Thermal interface material (TIM) and drivers are available (see datasheet for compatible parts). Suitable applications for the LUXEON PowerStars include: Emergency lighting, entertainment lighting, architectural lighting and tuneable lighting to name a few.
Features of the LUXEON PowerStar modules:
1 x LUXEON LED from LUMILEDS
200 mm wires
Up to 50000 hours lifetime (to 70% original brightness)
Can be linked together for longer chains
Compact and powerful
Intelligent LED Solutions LED Modules - PowerStars
