Multifunction Testers

Multifunction testers are handheld devices used to verify the safety of installations in domestic, commercial and industrial settings. These testers ensure that fixed wiring is safe and correctly installed to meet relevant local standards and safety requirements.Multifunction testers are ideal for testing a range of electrical parameters such as voltage, earth resistance, loop impedance and more. Many multifunction testers offer additional features such as Bluetooth, allowing you to store and transfer data from the device to a computer or mobile device.Here a RS Components we have sourced multifunction testers from leading brands such as Fluke, Megger, Gossen Metrawatt, RS PRO, and many more.

What are Multifunction testers also known as?

Multifucntion Testers can be categorised with many different naming conventions, they are also commonly called 'Electrical Testers' and also 'Multifunction Installation Testers'. However, even though they use slightly different names they all essentially do very similar things and due to their nature can be used in a range of different situations.

Uses of Multifunction Testers

Multifunction testers perform a variety of tests, including:Insulation-continuity tests: Diagnose breakdown of the insulation in various parts of the electrical system such as wires, transformers and motors. The quality of insulation is critical in ensuring uninterrupted and safe functioning of electrical circuitsChecking RCD devices: Check the proper functioning of residual-current devices (RCDs). RCDs are designed to disconnect quickly to mitigate the harm caused by electric shock and to avoid current leaks that may lead to fire and other dangerous situations.Loop testing: A quick, convenient, and specific method of evaluating an electrical circuit's ability to engage protective devices (circuit breakers, fuses, RCDs). A ground loop determines the effectiveness of protective devices.Resistance measurement of grounding systems: Verification tests to ensure that a system's resistance is low enough to provide protection to people, equipment and structures.

Application

Multifunction testers are used electrical engineers for electrical installation work in both commercial and industrial applications.


...
อ่านเพิ่มเติม อ่านน้อยกว่า

คัดกรอง / Filters

กำลังดูสินค้า 1 - 20 รายการจาก 24 รายการ / Viewing 1 - 20 of 24 products
ผลการค้นหาต่อหน้า / Results Per Page
รายละเอียดสินค้า / Description ราคา / Price Loop Impedance Test Type Automatic RCD Test RCD Ramp Test Non-Tripping Insulation Test Voltage Maximum Voltage Measurement Test Type Earth Resistance Measurement Downloadable Data Interface Type Continuity Test Current RCD Test Type Remote Switch Mode Test Standards
RS Stock No. 712-6023
หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.MI-3125
Brand :Metrel
THB35,465.21
Each
Units
3 Wire Yes - Yes - 550V ac Continuity Yes - - - - - -
RS Stock No. 117-6667
หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.FLK-1664FC SCH
Brand :Fluke
THB68,054.52
Each
Units
Phase to Earth, Phase to Neutral Yes Yes - 50 V, 100 V, 250 V, 500 V, 1000 V 500V ac/dc - Yes Yes BLE, USB 10mA A/F, AC Type, B/B+, G, S Yes -
RS Stock No. 292-1230
หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.Fluke T5-1000
Brand :Fluke
THB7,642.93
Each
Units
- - - - - 1000V ac AC Current, AC Voltage, Continuity, DC Current, DC Voltage, Resistance - - - - - - -
RS Stock No. 785-0717
หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.T5-600/62MAX +/1AC KIT
Brand :Fluke
THB11,070.56
Each
Units
- - - - - 600V ac AC Current, AC Voltage, DC Voltage, Resistance - - - - - - -
RS Stock No. 291-9372
หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.Fluke T5-600
Brand :Fluke
THB7,104.00
Each
Units
- - - - - 600V ac AC Current, AC Voltage, Continuity, DC Current, DC Voltage, Resistance - - - - - - -
RS Stock No. 899-8208
หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.M520T
THB42,487.97
Each
Units
3 Wire Yes Yes Yes 1000V 600V Wiring Polarity Yes - - 15mA AC Type, DC Selective Yes EN 61557, IEC 61557, VDE 0413
RS Stock No. 117-6666
หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.FLK-1663 SCH
Brand :Fluke
THB62,113.06
Each
Units
Phase to Earth, Phase to Neutral Yes Yes - 50 V, 100 V, 250 V, 500 V, 1000 V 500V ac/dc Continuity, Frequency, Insulation Resistance, Loop and Line Resistance, Measure Motor Windings, Phase Sequence Test, Prospective Earth Fault Current, Prospective Short Circuit Current, RCD Test, Resistance, Voltage, Wiring Polarity Yes - USB 10mA A/F, AC Type, B/B+, G, S Yes -
RS Stock No. 117-6665
หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.FLK-1662 SCH
Brand :Fluke
THB41,078.85
Each
Units
Phase to Earth, Phase to Neutral Yes Yes - 100 V, 250 V, 500 V, 1000 V 500V ac/dc Continuity, Frequency, Insulation Resistance, Loop and Line Resistance, Measure Motor Windings, Phase Sequence Test, Prospective Earth Fault Current, Prospective Short Circuit Current, RCD Test, Resistance, Voltage, Wiring Polarity - - - 10mA A/F, AC Type, G, S Yes -
RS Stock No. 794-3250
หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.PROINSTALL-200-D
Brand :Beha-Amprobe
THB49,228.67
Each
Units
3 Wire Yes Yes Yes 100 V, 250 V, 500 V, 1000 V 500V ac - Yes Yes Infrared 200mA AC Selective, DC Selective - BS7671, EN 61557, IEC 60364
RS Stock No. 731-8979
หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.Fluke T5-H5-1AC II/UK
Brand :Fluke
THB8,625.92
Each
Units
- - - - - 1000V ac AC Current, AC Voltage, Continuity, DC Voltage, Resistance - - - - - - -
RS Stock No. 799-9011
หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.P01157702
THB198,410.05
Each
Units
- No - - - - Current Transformation ratios, Power, Voltage - Yes USB - - - EN 61010-I
RS Stock No. 494-7650
หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.FLUKE T5-H5-1AC KIT
Brand :Fluke
THB7,914.27
Each
Units
- - - - - 1000V ac AC Current, AC Voltage, Continuity, DC Voltage, Resistance - - - - - - -
RS Stock No. 899-8205
หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.M503B
THB71,054.52
Each
Units
Phase to Earth, Phase to Neutral - Yes - 3700V 600V Wiring Polarity Yes - - 15mA DC Selective Yes DIN VDE 0100-600, IEC 60364-6
RS Stock No. 136-5806
หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.M520P
THB102,132.90
Each
Units
Line to Earth Yes Yes - 1000V 500V Auto Test, RCD Test, RCD Trip Current, RCD Trip Time Yes Yes Bluetooth - B, B+, G, R - IEC 60364-6, IEC 61851, IEC/EN 61010-1, IEC/EN 61557
RS Stock No. 136-5807
หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.M500V
THB114,734.54
Each
Units
Line to Earth Yes Yes - 1000V 500V Auto Test, RCD Test, RCD Trip Current, RCD Trip Time Yes Yes Bluetooth - B, B+, G, R - IEC 60364-6, IEC 61851, IEC/EN 61010-1, IEC/EN 61557
RS Stock No. 704-0487
หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.1002-415
Brand :Megger
THB59,822.89
Each
Units
2 Wire Yes Yes Yes 100 V, 250 V, 500 V, 1000 V 600V Continuity, Wiring Polarity Yes Yes German Mains 15 mA, 200 mA AC Type, DC Selective - BS 7671, IEC 60364, IEC 61010-031, IEC 61010-1, IEC 61010-30, IEC 61557, VDE 0100
RS Stock No. 811-1271
หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.M500W
THB121,333.37
Each
Units
- - - - - - - - - - - - - -
RS Stock No. 788-4580
หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.RSET5
Brand :Martindale
THB6,097.87
Each
Units
- - - - - 600V ac AC Current, AC Voltage, Capacitance, DC Current, DC Voltage, Resistance, Temperature - - - - - - -
RS Stock No. 136-5808
หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.M500Y
THB168,802.39
Each
Units
Line to Earth Yes Yes - 1000V 500V Auto Test, RCD Test, RCD Trip Current, RCD Trip Time Yes Yes Bluetooth - B, B+, G, R - IEC 60364-6, IEC 61851, IEC/EN 61010-1, IEC/EN 61557
RS Stock No. 867-5627
หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.M520R
THB83,017.57
Each
Units
- Yes Yes Yes 3700V 500V Wiring Polarity Yes Yes - - AC Type, DC Selective - IEC 60364-6
