Renesas Electronics, 16bit R8C/2D, R8C Microcontroller, 20MHz, 128 kB, 2 kB Flash, 80-Pin LQFP

Brand

Renesas Electronics

Family Name

R8C

Package Type

LQFP

Mounting Type

Surface Mount

Pin Count

80

Device Core

R8C/2D

Data Bus Width

16bit

Program Memory Size

128 kB, 2 kB

Maximum Frequency

20MHz

RAM Size

7.5 kB

USB Channels

0

Number of PWM Units

2 x 16 bit

Number of SPI Channels

0

Number of USART Channels

0

Typical Operating Supply Voltage

2.2 → 5.5 V

Number of CAN Channels

0

Number of UART Channels

3

Number of I2C Channels

1

Maximum Operating Temperature

+85 °C

Number of ADC Units

1

Program Memory Type

Flash

Number of PCI Channels

0

Number of Ethernet Channels

0

Number of LIN Channels

1

Height

1.4mm

Length

12.1mm

ADCs

20 x 10 bit

Instruction Set Architecture

CISC

Width

12.1mm

Pulse Width Modulation

1 x 16 bit, 2 x 16 bit

Maximum Number of Ethernet Channels

0

Minimum Operating Temperature

-20 °C

Dimensions

12.1 x 12.1 x 1.4mm
