เลือกทั้งหมด	คุณลักษณะ	ค่า
	Brand	STMicroelectronics
	Classification	Development Kit
	Kit Name	Nucleo Pack
	Technology	MCU
	Device Core	ARM Cortex M4
	Processor Family Name	ARM
	Processor Part Number	STM32F446RET6
	Processor Type	Microcontroller

	เลือกทั้งหมด
	Brand STMicroelectronics
	Classification Development Kit
	Kit Name Nucleo Pack
	Technology MCU
	Device Core ARM Cortex M4
	Processor Family Name ARM
	Processor Part Number STM32F446RET6
	Processor Type Microcontroller

COO (Country of Origin):: IT

STEVAL-IOM001V1
IO-Link master PHY based on L6360
Interrupt diagnostics pin
I²C and UART interface
SPI (slave) interface
65 mA selectable (3.3 or 5.0 V) linear regulator
CQ (push-pull) and L+ (high side) switches
IQ additional IEC61131-2 type 1 digital input
L+ and CQ overload and overheating protections with non-dissipative cut-off function
QFN-26L (3.5x5x1 mm) package
Operating voltage range from 18 to 32.5 V
Additional high side switch for L+ heavy loads
LEDs for status and diagnostics
Ground and VCC wire break protections
Equipped with ST morpho connectors
32-bit Micro-controller based on ARM®Cortex®-M4 core (180 MHz max.) with 512-Kbyte Flash memory and 128 (+4) Kbyte RAM
Two types of extension resources: Arduino™ UNO Revision 3 connectivity and ST morpho extension pin headers for full access to all STM32 I/Os
Mbed-enabled
On-board ST-LINK/V2-1 debugger/programmer with SWD connector: selection-mode switch to use the kit as a standalone ST-LINK/V2-1
Two push-buttons: USER and RESET

STMicroelectronics Nucleo Pack MCU Development Kit P-NUCLEO-IOM01M1

For these non-cancellable (NC), and non-returnable (NR) products, Terms and Conditions apply.
