    OLED Displays

    OLED displays are electronic visual displays based upon organic light-emitting diode (OLED) technology. Like other display types, an OLED Display can be used to present images, text and video a viewer.

    What is an OLED?

    An OLED is an organic light-emitting diode, that when current is applied emits light. An individual OLED is made up of an organic semiconductor, sandwiched between two electrodes. These electrodes is typically transparent, allowing the emitted light to escape.

    How does an OLED Display work?

    An OLED display is made up of an array of individual OLEDs that are individually turned on and off in a coordinated way (driven) to present an image. There are two main methods of driving an OLED display:

    • PMOLED (passive matrix OLED) – Each row and line of pixels in the display are controlled sequentially, one at a time.

    • AMOLED (active matrix OLED) – A thin-film transistor backplane is used to switch each pixel on and off, with each pixel containing a storage capacitor to maintain the on pixel state.

    Advantages

    High contrast ratio – OLEDs emit light directly, so when a black pixel is required, the pixel is off and emits no light at all. LCDs cannot achieve lower contrast ratios as black is achieved by masking a backlight, some light always get through

    Wide viewing angle – Because OLEDs emit light directly and not through a liquid crystal layer like in a LCD

    Response time – Current OLEDs can reach response times as low as 1 ms

    Disadvantages

    Lifespan – The organic materials used in the OLEDs have a limited lifespan compared to LCD displays

    Outdoor performance – OLED Displays utilise an emissive technology, meaning all the light used to make up an image is produced by the display. As the constituent OLEDs can act like a mirror, in high ambient light condition the image can be difficult to view.

    Power consumption – An OLED display will generally consume more power that an LCD display, unless the image is primarily black

    Uses:

    • PMOLED - Are typically used in small, graphical displays, where their benefits of a simple control scheme and low cost outweigh the disadvantages of restricted resolution and shorter lifespan.

    • AMOLED - Are typically used in applications that require higher resolutions and are large in size.

    180 สินค้าที่แสดงสำหรับ OLED Displays

    • RS Stock No. 225-6202
    • หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No. MDOB128064V2V-WI
    Each
    THB482.20
    Midas
    0.96in
    21.74 x 10.86mm
    -
    Passive
    White
    128 x 64pixels
    -
    2000:1
    COB
    I2C
    38.00 x 28.50 x 2.37mm
    2.37mm
    -
    2.37mm
    +80°C
    • RS Stock No. 254-3581
    • หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No. MDOB128032GV-WI
    Each
    THB287.42
    Midas
    0.91in
    22.38 x 5.58mm
    12.0:2.41
    Passive
    White
    128 x 32pixels
    -
    2000:1
    COB
    I2C
    35.8 x 12.0 x 2.41mm
    2.41mm
    -
    2.41mm
    +80°C
    • RS Stock No. 254-3587
    • หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No. MDOB128064XV-YI
    Each
    THB701.20
    Midas
    1.28in
    29.42 x 14.20mm
    32: 2.66
    Passive
    Yellow
    128 x 64pixels
    -
    2000:1
    COB
    I2C
    35.50 x 32.00 x 2.66mm
    2.66mm
    -
    2.66mm
    +80°C
    • RS Stock No. 264-3995
    • หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No. NHD-0220CW-AB3
    Each
    THB1,525.42
    NEWHAVEN DISPLAY INTERNATIONAL
    -
    77.92 x 16.28mm
    -
    -
    Blue
    -
    -
    -
    -
    I2C, Parallel, SPI
    -
    -
    None
    -
    +85°C
    • RS Stock No. 225-6196
    • หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No. MDOB064048AV-WI
    Each
    THB298.74
    Midas
    0.66in
    13.42 x 10.06mm
    -
    Passive
    White
    64 x 48pixels
    -
    2000:1
    COB
    I2C
    19.9 x 23.1 x 2.4mm
    2.4mm
    -
    2.4mm
    +80°C
    • RS Stock No. 225-6194
    • หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No. MDOB048064AV-WI
    Each
    THB285.47
    Midas
    0.71in
    10.54 x 14.70mm
    -
    Passive
    White
    48 x 64pixels
    -
    2000:1
    COB
    I2C
    15.90 x 27.00 x 2.36mm
    2.36mm
    -
    2.36mm
    +80°C
    • RS Stock No. 254-3593
    • หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No. MDOD128064A1D-WM
    Each
    THB1,120.08
    Midas
    0.96in
    22.74 x 11.86mm
    39.40:24.80
    Passive
    White
    128 x 64pixels
    -
    10000:1
    Dial
    I2C, SPI
    Ø39.40 x 24.80mm
    -
    -
    -
    +80°C
    • RS Stock No. 249-2722
    • หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No. MCOT128064H1V-YM
    Each
    THB1,346.42
    Midas
    2.42in
    55.01 x 27.49mm
    -
    Passive
    Yellow
    128 x 64pixels
    -
    2000:1
    TAB
    I2C, Parallel, SPI
    60.5 x 37.0 x 2.15mm
    2.15mm
    -
    2.15mm
    +80°C
    • RS Stock No. 249-2724
    • หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No. MCOT128064N2Z-YBM
    Each
    THB349.17
    Midas
    0.96in
    21.738 x 11.204mm
    -
    Passive
    Blue, Yellow
    128 x 64pixels
    -
    2000:1
    TAB
    I2C, Parallel, SPI
    26.7 x 19.26 x 1.65mm
    1.65mm
    -
    1.65mm
    +70°C
    • RS Stock No. 136-8065
    • หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No. 410-222
    Each
    THB542.65
    Digilent
    -
    -
    -
    Active
    Blue
    128 x 32pixels
    -
    -
    -
    SPI
    -
    -
    -
    -
    -
    • RS Stock No. 428-549
    • หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No. MDOG128040AV-WM
    Each
    THB335.48
    Midas
    1.3in
    31.852 X 8.66mm
    -
    -
    White
    128 X 40pixels
    -
    -
    COG
    I2C, SPI
    -
    -
    -
    -
    -
    • RS Stock No. 254-3595
    • หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No. MDOD128128A1B-WMC
    Each
    THB2,623.84
    Midas
    1.18in
    30.0 x 30.0mm
    56: 21.56
    Passive
    White
    128 x 128pixels
    -
    10000:1
    CTP Dial
    I2C, SPI
    Ø56.00 x 21.56mm
    -
    -
    -
    +50°C
    • RS Stock No. 254-3597
    • หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No. MDOG128032A1V-YI
    Each
    THB302.06
    Midas
    0.91in
    24.384 x 7.584mm
    11.50:1.26
    Passive
    Yellow
    128 x 32pixels
    -
    2000:1
    COG
    I2C
    30.00 x 11.50 x 1.26mm
    1.26mm
    -
    1.26mm
    +80°C
    • RS Stock No. 254-3607
    • หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No. MDOT256064G1V-WM
    Each
    THB834.41
    Midas
    2.08in
    51.18 x 12.78mm
    19:1.6
    Passive
    White
    256 x 64pixels
    -
    2000:1
    COT
    I2C, Parallel, SPI
    60.50 x 19.00 x 1.60mm
    1.60mm
    -
    1.60mm
    +80°C
    • RS Stock No. 150-479
    • หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No. NHD-1.8-160128B
    Each
    THB909.80
    NEWHAVEN DISPLAY INTERNATIONAL
    1.8in
    37.015 x 30.012mm
    1.23
    Passive
    Full Colour
    160 x 128pixels
    -
    -
    PCB Mount
    Parallel, SPI
    -
    -
    -
    -
    -
    • RS Stock No. 254-3557
    • หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No. MCOT064048A1V-WM
    Each
    THB287.36
    Midas
    0.66in
    15.42 x 12.06mm
    18.10:1.3
    Passive
    White
    64 x 48pixels
    -
    2000:1
    COT
    I2C, Parallel, SPI
    18.46 x 18.10 x 1.3mm
    1.3mm
    -
    1.3mm
    +80°C
    • RS Stock No. 331-031
    • หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No. NHD-1.69-160128B
    Each
    THB870.69
    NEWHAVEN DISPLAY INTERNATIONAL
    1.69in
    35.57 x 28.86mm
    -
    Passive
    Full Colour
    160 x 128pixels
    -
    -
    PCB Mount
    I2C, Parallel, SPI
    -
    -
    -
    -
    -
    • RS Stock No. 254-3601
    • หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No. MDOG128064N4V-YM
    Each
    THB339.19
    Midas
    0.96in
    23.34 x 11.46mm
    19.26:1.26
    Passive
    Yellow
    256 x 64pixels
    -
    2000:1
    COG
    I2C, Parallel, SPI
    26.70 x 19.26 x 1.26mm
    1.26mm
    -
    1.26mm
    +80°C
    • RS Stock No. 181-329
    • หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No. NHD-2.8-25664UCY2
    Each
    THB1,664.70
    NEWHAVEN DISPLAY INTERNATIONAL
    2.8in
    72 x 20mm
    -
    Passive
    Yellow
    256 x 64pixels
    -
    -
    PCB Mount
    Parallel, SPI
    -
    -
    -
    -
    -
    • RS Stock No. 254-3600
    • หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No. MDOG128064N4V-WM
    Each
    THB347.44
    Midas
    0.96in
    23.34 x 11.46mm
    19.26:1.26
    Passive
    White
    128 x 64pixels
    -
    2000:1
    COG
    I2C, Parallel, SPI
    26.70 x 19.26 x 1.26mm
    1.26mm
    -
    1.26mm
    +80°C
