- RS Stock No.:
- 721-1412
- หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:
- 1519752
- ผู้ผลิต / Manufacturer:
- Phoenix Contact
- RS Stock No.:
- 721-1412
- หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:
- 1519752
- ผู้ผลิต / Manufacturer:
- Phoenix Contact
ข้อมูลทางเทคนิค / Technical Data Sheets
Legislation and Compliance
- COO (Country of Origin):
- DE
รายละเอียดสินค้า / Product Details
M8 and M12 adapter
These SAC-3P adapters from Phoenix Contact are a range of M8 to M12, or M12 to M8 adapters that are perfect for either permanent solutions or quick, field connections. They're a standard coding 'A' and come backed by an excellent IP67 rating when mated with other connectors for versatile uses. Not to mention, they can work in harsh conditions.
The easy plugin system allows effortless connection of sensor and actuator cables to have your systems up and running in a fraction of the time than splicing other circular connectors onto cables. SAC-3P adapters have been built with quality in mind, as the housing is built from durable plastic, with zinc metal knurls holding the connectors in place.
The easy plugin system allows effortless connection of sensor and actuator cables to have your systems up and running in a fraction of the time than splicing other circular connectors onto cables. SAC-3P adapters have been built with quality in mind, as the housing is built from durable plastic, with zinc metal knurls holding the connectors in place.
Features and benefits:
Sensor/ actuator adapter for the transition of M8 to M12
SAC-3P 1519752 - M12 to M8 adapter
The 1519752 includes all the same specifications as above. It's an M12 to M8 adapter with 3-positions on both M connections. The M12 connector is the male with the M8 being a female connection.
Phoenix Contact - PLUSCON field
คุณสมบัติ / Specifications
คุณสมบัติ | Value |
---|---|
End 1 | M12 |
End 1 Number of Contacts | 3 |
End 1 Number of Ports | 1 |
End 1 Gender | Male |
End 2 | 3 Pin Female M8 (1) |
End 1 Size | M12 |
End 2 Number of Contacts | 3 |
End 2 Number of Ports | 1 |
End 2 Gender | Female |
End 2 Size | M8 |
Current Rating | 4A |
IP Rating | IP65, IP67 |
Voltage Rating | 60 V |
Body Orientation | Straight |
Maximum Operating Temperature | +90°C |
Contact Plating | Gold over Nickel |
Shell Plating | Nickel |
Contact Material | Copper Tin Alloy |
Minimum Operating Temperature | -25°C |
Length | 50.5mm |
