RF Terminators

RF terminators are devices used to electrically terminate coaxial RF (radio frequency) ports. They are usually placed at the end of the transmission line to prevent an RF signal from being reflected.

RF terminators are designed to match the surge impedance (ratio of current and voltage) of the cable to help minimise signal reflections and power losses. Unused tap ports or coaxial faceplates in a home, for example, can create entry and exit paths, which affect performance.

How do RF terminators work?

RF terminators absorb the electrical energy of the signal as it reaches the cable ends and prevents the signal from being reflected so it doesn’t become noise. They ensure that current flows smoothly from one device to another.

What are RF terminators used for?

RF terminators play a critical role in high-frequency systems and circuits, especially when managing high-power signals. They can also be used to close open terminations that might otherwise allow parasitic signals to enter the circuit, such as at a T-junction.

RF terminators are available in many form factors with power ratings to match their sizes.


...
อ่านเพิ่มเติม อ่านน้อยกว่า

คัดกรอง / Filters

กำลังดูสินค้า 1 - 20 รายการจาก 81 รายการ / Viewing 1 - 20 of 81 products
ผลการค้นหาต่อหน้า / Results Per Page
รายละเอียดสินค้า / Description ราคา / Price Interface Type Gender Body Orientation Mounting Type Impedance Body Plating Cable Type Operating Frequency Average Power Rating Low Power Contact Material Contact Plating
RS Stock No. 546-4128
Brand :RS PRO
THB117.67
Each
Units
BNC Male Straight - 50Ω - - 1GHz 0.5W - Brass Gold
RS Stock No. 546-4695
Brand :RS PRO
THB481.60
Each
Units
BNC Female, Male Straight Through Hole 50Ω Silver - 0 → 0.5GHz 2W - Brass Gold
RS Stock No. 546-4673
Brand :RS PRO
THB109.87
Each
Units
BNC Male Straight - 50Ω Silver - 0 → 1GHz 0.5W - Brass Gold
RS Stock No. 546-4689
Brand :RS PRO
THB111.28
Each
Units
BNC Male Straight - 75Ω Silver - 0 → 1GHz 0.5W - Brass Gold
RS Stock No. 546-4134
Brand :RS PRO
THB103.00
Each
Units
BNC Male Straight - 75Ω Nickel - 0 → 1GHz 0.5W - Brass Gold
RS Stock No. 112-3148
หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.J01006A1268
Brand :Telegartner
THB207.84
Each
Units
BNC Male Straight - 50Ω - - - 0.5W - - -
RS Stock No. 458-8560
หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.J01026A0012
Brand :Telegartner
THB1,072.62
Each
Units
N Male Straight - 50Ω - - 6GHz 1W - - -
RS Stock No. 716-5019
หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.65_N-50-0-51/113_NE
Brand :Huber+Suhner
THB522.26
Each
Units
N Male Straight - 50Ω White Bronze - 0 → 6GHz 1W - Brass White Bronze
RS Stock No. 170-2499
หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.B1004A1-ND3G-50R-0.01-1W
Brand :Amphenol RF
THB232.77
Each (In a Bag of 100)
Units
BNC Male Straight - 50Ω Nickel over Copper - - - - Brass Gold over Nickel
RS Stock No. 263-2716
หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.R404101000W
Brand :Radiall
THB139.63
Each
Units
SMA Male Straight - 50Ω - - 0 → 4GHz 1W - - -
RS Stock No. 168-0632
หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.1-1337463-0
THB96.967
Each (In a Box of 1000)
Units
BNC Male Straight - 50Ω Silver - 0 → 1GHz 0.5W - Brass (Center Contact) Silver (Center Contact)
RS Stock No. 161-6049
หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.1-1337463-0
THB140.486
Each (In a Bag of 50)
Units
BNC Male Straight - 50Ω - - 0 → 1GHz 0.5W - - -
RS Stock No. 846-6691
หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.1-1337463-0
THB167.07
Each
Units
BNC Male Straight - 50Ω Silver - 0 → 1GHz 0.5W - Brass (Center Contact) Silver (Center Contact)
RS Stock No. 716-4984
หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.65_BNC-50-0-7/133_NE
Brand :Huber+Suhner
THB631.24
Each
Units
BNC Male Straight - 50Ω White Bronze - 0 → 1GHz 1W - Brass Gold over Nickel
RS Stock No. 712-3286
หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.J01152B0011
Brand :Telegartner
THB846.01
Each
Units
SMA Male Straight - 50Ω Copper Nickel Gold Alloy - 0 → 18GHz 1W - Brass, Lead Alloy Copper, Gold Alloy, Nickel
RS Stock No. 394-1077
หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.1-1337463-0
THB167.07
Each
Units
BNC Male Straight - 50Ω - - 0 → 1GHz 0.5W - - -
RS Stock No. 700-9313
หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.B1004A1-ND3G-50R-0.01-1W
Brand :Amphenol RF
THB193.91
Each
Units
BNC Male Straight - 50Ω Nickel over Copper - - - - Brass Gold over Nickel
RS Stock No. 494-739
หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.65_SMA-50-0-1/111_NE
THB861.61
Each
Units
SMA Male Straight - 50Ω Gold over Nickel - 0 → 18GHz 1W Yes Brass Gold over Nickel
RS Stock No. 124-9149
หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.J01006A1373
Brand :Telegartner
THB420.26
Each
Units
BNC Male Straight - 93Ω - - 0 → 600MHz 0.5W - Brass -
RS Stock No. 716-5012
หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.6550.17.AA
Brand :Huber+Suhner
THB7,062.50
Each
Units
N Male Straight - 50Ω Anodized - 0 → 5GHz 25W - Brass Gold
