Omron H3RN Series Panel Mount Timer Relay, 12V dc, 1-Contact, 0.1 min → 100h, DPST
- RS Stock No.:
- 177-0105
- หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:
- H3RN-21-B DC12
- ผู้ผลิต / Manufacturer:
- Omron
สินค้าหมดชั่วคราว (Temporarily out of stock) - จะเป็นแบ๊คออเดอร์จัดส่ง (back order for despatch) 08/07/2024, จัดส่งภายใน (delivery within) 4-6 วันทำการ (working days)
เพิ่ม / Added
ราคา / Price Each
THB2,926.53
(exc. VAT)
THB3,131.39
(inc. VAT)
| Units | Per unit |
| 1 + | THB2,926.53 |
- RS Stock No.:
- 177-0105
- หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:
- H3RN-21-B DC12
- ผู้ผลิต / Manufacturer:
- Omron
ข้อมูลทางเทคนิค / Technical Data Sheets
Legislation and Compliance
- COO (Country of Origin):
- JP
รายละเอียดสินค้า / Product Details
Omron Timer Relay
The Omron H3RsN is compact, multifunction ON delay timer. It has multiple operating modes and time ranges. It is a panel mount timer that has a push-in plus terminal block. The relay requires a supply voltage of 12VDC and a maximum current rating of 3A. It has an adjustable time range between 0.1min and 100hours.
Features and Benefits
• Contact configuration is DPST
• Operating temperature range between -10°C and 55°C
• Reduce wiring time
• Terminal type is plugin
• Operating temperature range between -10°C and 55°C
• Reduce wiring time
• Terminal type is plugin
Applications
• Automation
• Industrial application
• Industrial application
Certifications
• CE certified
• CSA approved
• UL 508
• CSA approved
• UL 508
For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.
คุณสมบัติ / Specifications
คุณสมบัติ | Value |
|---|---|
| Supply Voltage | 12V dc |
| Mounting Type | Panel Mount |
| Mode of Operation | Flicker OFF Start, Flicker ON Start, Interval, ON Delay |
| Time Range | 0.1 min → 100h |
| Number of Contacts | 1 |
| Number of Timer Functions | Multi Function |
| Contact Configuration | DPST |
| Time Increment | Hours, Minutes |
| Maximum Current | 3A |
| Maximum Voltage | 12V dc |
| Switch Configuration | DPST |
| Terminal Type | Plug In |
| Width | 31.2mm |
| Power Supply | External |
| Series | H3RN |
| Depth | 47.2mm |
| Length | 12.8mm |
| Maximum Operating Temperature | +55°C |
| Minimum Current | 10mA |
| Contact Material | AgSnln |
| Minimum Operating Temperature | -10°C |
