Maxim Integrated MAX15162ATG Evaluation Kit Power Supply for MAX15162ATG for MAX15162AATG+, MAX15162ATG+

The Maxim Integrated The MAX15162TA evaluation kit (EV kit) is a fully assembled and tested surface-mount circuit board that contains all components necessary to evaluate the MAX15162ATG+/MAX15162AATG+ dual-channel circuit breaker IC for power amplifier system. The IC is in compact24-pin, 4mm x 4mm TQFN package. The EV kit is powered from an 8V to 60V DC supply and can be configured as two independent single-channels or one parallel dual-channel circuit breaker. The EV kit provides multilevel overcurrent limit protection and pin-strap programmable current-limit level up to 1.5A for each channel.

8V to 60V Wide Input Voltage Range
Integrated Dual-Power MOSFET with Turn-on
Resistance 200mO
Dual-Channel Independent or Parallel Mode
Configuration
Under voltage Lockout
Enable Input for Individual Channel
Constant Power Control at Start-up
Start-up Watchdog Timer
Start-up IN-to-OUT Short Protection
Over-current and Over temperature Fault Status Indication on Individual Channel
±3% Accuracy Current Reporting on Individual Channel
Multi-Level Overcurrent Limit Protection
Programmable Current Limit Level
