- RS Stock No.:
- 188-1442
- หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:
- NRF6707
- ผู้ผลิต / Manufacturer:
- Nordic Semiconductor
ดูหมวดหมู่นี้
- RS Stock No.:
- 188-1442
- หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:
- NRF6707
- ผู้ผลิต / Manufacturer:
- Nordic Semiconductor
ข้อมูลทางเทคนิค / Technical Data Sheets
Legislation and Compliance
รายละเอียดสินค้า / Product Details
Variable power supply voltage ranging from 1.8 V to 3.6 V (software configurable)
Maximum 70 mA current measurement
Resolution down to 0.2 μA
Automatic switching between three current measurement ranges ensuring optimal resolution
Measurement accuracy better than +/-20 % (average currents measurement)
Desktop application for measurement analysis
Real-time current measurement display
Recording display up to two minutes
Real-time display with a resolution down to 13 μs
Internal/external trigger
Applications
Quick power consumption measurements on a firmware running on an nRF5 DK
Quick power consumption measurements on a firmware running on an external board
Accumulative measurements, such as average, peak, maximum
Instantaneous measurements presented as waveform plots
Maximum 70 mA current measurement
Resolution down to 0.2 μA
Automatic switching between three current measurement ranges ensuring optimal resolution
Measurement accuracy better than +/-20 % (average currents measurement)
Desktop application for measurement analysis
Real-time current measurement display
Recording display up to two minutes
Real-time display with a resolution down to 13 μs
Internal/external trigger
Applications
Quick power consumption measurements on a firmware running on an nRF5 DK
Quick power consumption measurements on a firmware running on an external board
Accumulative measurements, such as average, peak, maximum
Instantaneous measurements presented as waveform plots
คุณสมบัติ / Specifications
คุณสมบัติ | Value |
---|---|
Power Management Function | Current Measurement |
For Use With | Oscilloscope and Logic Analyzers |
Kit Name | Power Profiler Kit |
