Roxburgh EMC, IHF 8A 480 V ac 60Hz, Flange Mount RFI Filter, Stud, Single Phase
- RS Stock No.:
- 188-9163
- หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:
- IHF408
- ผู้ผลิต / Manufacturer:
- Roxburgh EMC
สินค้าหมดชั่วคราว (Temporarily out of stock) - จะเป็นแบ๊คออเดอร์จัดส่ง (back order for despatch) 09/07/2024, จัดส่งภายใน (delivery within) 4-6 วันทำการ (working days)
เพิ่ม / Added
ราคา / Price Each
THB5,399.18
(exc. VAT)
THB5,777.12
(inc. VAT)
| Units | Per unit |
| 1 - 24 | THB5,399.18 |
| 25 - 49 | THB5,183.21 |
| 50 - 99 | THB4,967.25 |
| 100 + | THB4,859.26 |
- RS Stock No.:
- 188-9163
- หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:
- IHF408
- ผู้ผลิต / Manufacturer:
- Roxburgh EMC
ข้อมูลทางเทคนิค / Technical Data Sheets
Legislation and Compliance
- COO (Country of Origin):
- GB
รายละเอียดสินค้า / Product Details
IHF/MDF Series
Motor drive filters suitable for a wide range of industrial motor applications
IHF variants offer three phase and neutral connection with low leakage current, (≤3.5mA)
MDF variants offer higher performance for applications where leakage current is not a limiting factor (three phase connection with no neutral)
Designed to comply with IEC950 safety standards, when installed correctly these filters allow compliance with VDE0871, EN55011 (Industrial) and EN55022 (Domestic) emission levels
IHF variants offer three phase and neutral connection with low leakage current, (≤3.5mA)
MDF variants offer higher performance for applications where leakage current is not a limiting factor (three phase connection with no neutral)
Designed to comply with IEC950 safety standards, when installed correctly these filters allow compliance with VDE0871, EN55011 (Industrial) and EN55022 (Domestic) emission levels
Approvals
IEC950; VDE0871; EN55011; EN55022
คุณสมบัติ / Specifications
คุณสมบัติ | Value |
|---|---|
| Maximum Current Rating | 8A |
| Maximum Voltage Rating | 480 V ac |
| Mounting Type | Flange Mount |
| Termination Style | Stud |
| Number of Phases | 1 |
| Series | IHF |
| Operating Frequency | 60Hz |
| Length | 230mm |
| Depth | 147mm |
| Height | 55mm |
| Capacitance | 1µF |
| Dimensions | 230 x 147 x 55mm |
| Inductance | 1.4 mH |
| Leakage Current | 0.6 mA |
| Minimum Operating Temperature | -25°C |
| Maximum Operating Temperature | +85°C |
| Resistance | 15mΩ |
| Power Loss | 1W |
| Standards Met | EN 60939 |
