Silicon Labs EFM32WG360F64G-A-CSP81, 32bit ARM Cortex M4 MCU, 48MHz, 64 kB Flash, 81-Pin CSP

  • RS Stock No. 169-0120
  • หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No. EFM32WG360F64G-A-CSP81
  • ผู้ผลิต / Manufacturer Silicon Labs
ข้อมูลทางเทคนิค / Technical Data Sheets
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): TW
รายละเอียดสินค้า / Product Details

EFM32 Wonder Gecko Microcontroller Family

Wonder Gecko (WG) family of energy friendly 32-bit microcontrollers, based on the ARM Cortex-M4 processor core.

EFM32 Gecko Microcontrollers

Silicon Labs microcontrollers target energy sensitive applications, including smart metering, gas/energy/water metering, remote sensing, building automation, security systems, portable health/fitness equipment and smart accessories.

Powerful ARM Cortex-M 32-bit processor cores
Short wake-up time from energy saving modes
Ideal for use with energy harvesting systems

คุณสมบัติ / Specifications
คุณสมบัติ Value
Family Name EFM32WG
Package Type CSP
Mounting Type Surface Mount
Pin Count 81
Device Core ARM Cortex M4
Data Bus Width 32bit
Program Memory Size 64 kB
Maximum Frequency 48MHz
RAM Size 32 kB
USB Channels 1 x OTG
ADC Channels 4, 8
Number of SPI Channels 1
Typical Operating Supply Voltage 1.98 → 3.8 V
Number of UART Channels 3
Number of Timers 4
Number of I2C Channels 2
Minimum Operating Temperature -40 °C
Instruction Set Architecture RISC
ADC Resolution 12bit
Number of ADC Units 1
Maximum Operating Temperature +85 °C
Length 4.36mm
ADCs 4-ch x 12-bit, 8-ch x 12-bit
Timer Resolution 16bit
Height 0.379mm
Width 4.275mm
Number of USART Channels 3
Timers 4 x 16 bit
Dimensions 4.355 x 4.275 x 0.379mm
Pulse Width Modulation 1
Program Memory Type Flash
สินค้าหมดชั่วคราว (Temporarily out of stock) - จะเป็นแบ๊คออเดอร์จัดส่ง (back order for despatch) 16/09/2020, จัดส่งภายใน (delivery within) 4-6 วันทำการ (working days)
ราคา / Price Each (On a Tape of 100)
THB 120.625
(exc. VAT)
THB 129.069
(inc. VAT)
Units
Per unit
Per Tape*
100 +
THB120.625
THB12,062.50
*ตัวบ่งบอกราคา / price indicative
