Microchip Technology ATMEGA649P-MU, 8bit AVR Microcontroller, 16MHz, 64 kB Flash, 64-Pin QFN/MLF

  • RS Stock No. 131-0332
  • หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No. ATMEGA649P-MU
  • ผู้ผลิต / Manufacturer Microchip
ข้อมูลทางเทคนิค / Technical Data Sheets
Legislation and Compliance
RoHS Certificate of Compliance
รายละเอียดสินค้า / Product Details

8-Bit megaAVR Microcontrollers with LCD Controller, Atmel

These megaAVR® microcontrollers feature an LCD controller and offer substantial program and data memories with performance up to 20 MIPS. All megaAVR microcontrollers offer self-programmability for fast, secure, cost-effective in-circuit upgrades.

คุณสมบัติ / Specifications
คุณสมบัติ Value
Family Name ATmega
Package Type QFN/MLF
Mounting Type Surface Mount
Pin Count 64
Device Core AVR
Data Bus Width 8bit
Program Memory Size 64 kB
Maximum Frequency 16MHz
RAM Size 4 kB
Number of PWM Units 1
ADC Channels 8
Typical Operating Supply Voltage 1.8 → 5.5 V
PWM Channels 4
Width 9.1mm
ADC Resolution 10bit
Timers 1(1 x 16 bit), 1(2 x 8 bit)
Minimum Operating Temperature -40 °C
Maximum Operating Temperature +85 °C
Timer Resolution 8 bit, 16 bit
Height 0.95mm
Instruction Set Architecture RISC
Pulse Width Modulation 1(4 Channel)
Dimensions 9.1 x 9.1 x 0.95mm
Program Memory Type Flash
Number of ADC Units 1
Number of Timers 2
ADCs 1(8 x 10 bit)
Length 9.1mm
ผลิตภัณฑ์ที่เลิกผลิตแล้ว
