Ampire AM-640480G2TNQW-00H-C TFT TFT LCD Display, 5.7in, 640 x 480pixels

RS Stock No.:: 188-4291
หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:: AM-640480G2TNQW-00H-C
ผู้ผลิต / Manufacturer:: Ampire

Ampire AM-640480G2TNQW-00H-C TFT TFT LCD Display, 5.7in, 640 x 480pixels

3 มีของพร้อมจัดส่งภายใน (In stock for delivery within) 4-6 วันทำการ (working days)

เพิ่ม / Added

ราคา / Price Each

THB8,046.73

(exc. VAT)

THB8,610.00

(inc. VAT)

Units	Per unit
1 - 4	THB8,046.73
5 - 9	THB7,724.85
10 - 24	THB7,402.97
25 +	THB7,242.04

RS Stock No.:: 188-4291
หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:: AM-640480G2TNQW-00H-C
ผู้ผลิต / Manufacturer:: Ampire

ข้อมูลทางเทคนิค / Technical Data Sheets

Legislation and Compliance

COO (Country of Origin):: TW

รายละเอียดสินค้า / Product Details

This is a color active matrix TFT-LCD that uses amorphous silicon TFT as a switching device. This model is composed of a 5.7inch TFT-LCD panel, a driving circuit and LED backlight system. This TFT-LCD has a high resolution (640(R.G.B) X 480) and can display up to 262,144 colors.

VGA Resolution
6 Bits color driver with 1 channel TTL interface
Wide range operation temperature
Improved inner FPC material to better reliability

คุณสมบัติ / Specifications

คุณสมบัติ	Value
Diagonal Display Size	5.7in
Resolution	640 x 480pixels
Touch Screen	No
Viewing Area Dimensions	115 x 86mm
Supply Voltage	3.3 V
Backlight Type	LED
Dimensions	127 x 6.6 x 98.43mm
Display Matrix Technology	TFT
Minimum Operating Temperature	-20°C
Maximum Operating Temperature	+70°C
Brightness	1000cd/m²
Width	127mm
Depth	6.6mm
Response Time	50ms
Operating Temperature Range	-20 → +70°C
Power Dissipation	270 (Consumption)mW
Viewing Area Width	115.2mm
Voltage Rating	3.3V
Contrast Ratio	250:1
Viewing Area Height	86.4mm
Series	AM640480G2
Display Type	TFT LCD
Power Supply Included	Yes
Height	98.43mm
