Hirschmann E Series, 5 Pole Cable Mount M12 Connector Plug, with Male Contacts, IP67

  • RS Stock No. 290-6584
  • หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No. 933163100
  • ผู้ผลิต / Manufacturer Hirschmann
ข้อมูลทางเทคนิค / Technical Data Sheets
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): HU
รายละเอียดสินค้า / Product Details

Hirschmann E Series Rewireable Connector

Brought to you by Hirschmann, this rewireable M12 receptacle is suitable for harsh environments. With an easy to assemble construction, these 4 and 5 pole receptacles are ideal for constructing customised jumper cables or for quickly replacing existing sockets. With a PG7 cable gland and with built-in stain relief with a cage clamp, this E Series M12 socket is robust and reliable. With high ingress protection, this connector is suited to use in dusty or damp conditions.

Features and Benefits

• Easy to assemble, no special tooling required
• PG7 cable gland and integral strain relief
• Excellent resistance to vibration and shock
• Ideal for jumper cable assemblies
• 4 and 5 pole plugs and sockets
• Straight and 90° cable entry
• IP67 ingress protection

Product Application Information

Often referred to as sensor connectors, M12 Circular connectors are used in sensor, industrial automation, robotics and other Input/Output applications. Their high-quality screw connection means that they offer excellent protection against vibration and ingress, ensuring a secure and reliable connection. The M12 connector is also used in almost all field bus applications.

• Assembly lines
• Robotics
• Material handling
• Process Control
• Industrial automation
• Instrumentation
• Factory automation

Environment

The Hirschmann M12 E series connectors are waterproof and have an IP67 ingress rating. This means they are totally sealed from dust and are protected from water jets from all directions. They are ideal in applications where machinery is likely to be washed down or other similar harsh environments.

FAQ

A – Yes, the E series of re-wireable connectors have screw termination. Quick and easy, reducing valuable assembly time.
Q – How robust are the connectors?
A - This range of connectors are manufactured from high-grade engineering materials. They are strong and reliable

Note

Plugs and sockets must be ordered individually

Hirschmann - M8 og M12

คุณสมบัติ / Specifications
คุณสมบัติ Value
Number of Contacts 5
Gender Male
Mounting Type Cable Mount
Plug/Socket Plug
Connector Size M12
Termination Method Screw
Current Rating 4A
IP Rating IP67
Contact Gender Male
Voltage Rating 50 V ac
Mating Type Threaded
Body Orientation Straight
Series E
Housing Material PA
Strain Relief Yes
Contact Plating Tin
Contact Material Brass
Maximum Operating Temperature +90°C
Minimum Operating Temperature -25°C
286 ภายใน (Within) 5 วันทำการ (working days)
2250 ภายใน (Within) 4-6 วันทำการ (สต๊อกทั่วโลก) (working days (Global stock))
ราคา / Price Each
THB 207.77
(exc. VAT)
THB 222.31
(inc. VAT)
Units
Per unit
1 - 9
THB207.77
10 - 49
THB205.40
50 - 99
THB202.47
100 - 249
THB199.33
250 +
THB196.17
