SMC, 3.5 SCFM Flow Controller

  • RS Stock No. 161-3093
  • หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No. AS1002FS-04
  • ผู้ผลิต / Manufacturer SMC
ข้อมูลทางเทคนิค / Technical Data Sheets
Legislation and Compliance
สถานะRoHS: ไม่สามารถใช้ได้
COO (Country of Origin): JP
รายละเอียดสินค้า / Product Details

SMC series AS*002F, in-line type, compact speed controllers with built in one-touch fittings minimize installation time, reduce mounting height, and enable a more compact machine design. These speed controls can be mounted in 4 variations (direct mounting, L-bracket mounting, DIN rail mounting & holder mounting). Available tube sizes range from 3.2mm to 12mm OD (metric) and 1/8 to 1/2 OD (inch). The AS*002F speed control series is RoHS compliant

In-line, compact, one-touch fittings
Maximum operating pressure: 1 MPa
Applicable tube material: nylon, soft nylon, polyurethane
Body size: M3, M5, 1/8, 1/4, 3/8 and 1/2

คุณสมบัติ / Specifications
คุณสมบัติ Value
Maximum Flow Rate 3.5 SCFM
Mounting Style L-Bracket Mount
Pipe Diameter Range 4 mm
Minimum Operating Temperature -5°C
Maximum Operating Temperature 60°C
Series AS
For Use With Airline Equipments
สินค้าหมดชั่วคราว, จะเป็นแบ๊คออเดอร์จัดส่งเมื่อในสต๊อกมีของพร้อมส่ง
ราคา / Price Each
คือ THB611.60
THB 567.80
(exc. VAT)
THB 607.55
(inc. VAT)
Units
Per unit
1 +
THB567.80
