Crouzet Syr-Line Series Panel Mount Timer Relay, 24V ac/dc, 1-Contact, 0.001 → 9.999 s, 0.01 → 99.99 s,

RS Stock No.:: 166-3808
หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:: MDE1R0524U
ผู้ผลิต / Manufacturer:: Crouzet

Crouzet Syr-Line Series Panel Mount Timer Relay, 24V ac/dc, 1-Contact, 0.001 → 9.999 s, 0.01 → 99.99 s,

5 มีของพร้อมจัดส่งจากคลังสินค้าทั่วโลก (Global stock) ภายใน (Within) 4-6 วันทำการ (working days)

18 มีของพร้อมจัดส่งจากคลังสินค้าทั่วโลก (Global stock) ภายใน (Within) 4-6 วันทำการ (working days)

เพิ่ม / Added

ราคา / Price Each

THB6,292.12

(exc. VAT)

THB6,732.57

(inc. VAT)

Units	Per unit
1 +	THB6,292.12

RS Stock No.:: 166-3808
หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:: MDE1R0524U
ผู้ผลิต / Manufacturer:: Crouzet

ข้อมูลทางเทคนิค / Technical Data Sheets

Datasheet

Legislation and Compliance

COO (Country of Origin):: CN

รายละเอียดสินค้า / Product Details

Crouzet Multi-Function Timer Relay

The Crouzet multi-function timer relay is a compact device with SPDT output. It performs the function of providing on delay in a one-shot, on delay, off delay, interval delay, symmetrical flashing on and off form in the range of 0.05 seconds to 9999 hours.

Features and Benefits

Large LCD screen of 13.2 mm
1 relay output changeover (24VAC/DC and 5A)
Basic and advance configuration modes
SPDT switching configuration

Memory option in an event of a break in supply
Lock function
Up and down timing
DIN sized 48mm x 48mm housing
Compact body (63mm long)
Water and dust-proof
8-pin connections

Applications

Textiles
Chemical industry
Mining
Irrigation
Raw material handling
Food and beverages
Industrial process control

Certifications

IP20 rated
IP66 rated
UL94 approved
IEC 60664-1
IEC 1812-1
IEC 60068-2-30
IEC 60068-2-6
IEC60068-2-27
IEC 60068-2-32

คุณสมบัติ / Specifications

คุณสมบัติ	Value
Supply Voltage	24V ac/dc
Mounting Type	Panel Mount
Mode of Operation	Interval, OFF Delay (Delay on Break), ON Delay (Delay on Make), One Shot, Symmetrical Flashing (OFF Start), Symmetrical Flashing (ON Start)
Time Range	0.001 → 9.999 s, 0.01 → 99.99 s, 0.1 → 999.9 min, 0.1 → 999.9 h, 0.1 → 999.9 s, 1 min → 99 h 59 min, 1 s → 99 min 59 s, 1 → 9999 h, 1 → 9999 s, 1 → 9999min
Number of Contacts	1
Number of Timer Functions	Multi Function
Contact Configuration	SPDT
Time Increment	Hours, Minutes, Seconds
Maximum Current	5A
Maximum Voltage	24V ac/dc
Terminal Type	Plug In
Switch Configuration	SPDT
Power Supply	External
Width	48mm
Depth	68mm
Minimum Current	3A
Length	48mm
Maximum Operating Temperature	+60°C
Series	Syr-Line
Minimum Operating Temperature	-10°C
