XP Power Switching Regulator, Surface Mount, 5V dc Output Voltage, 6.5 → 36V dc Input Voltage, 1A Output
- RS Stock No.:
- 178-3464
- หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:
- STS1024S05
- ผู้ผลิต / Manufacturer:
- XP Power
สินค้าหมดชั่วคราว (Temporarily out of stock) - จะเป็นแบ๊คออเดอร์จัดส่ง (back order for despatch) 18/04/2024, จัดส่งภายใน (delivery within) 4-6 วันทำการ (working days)
ราคา / Price 1 Tube of 30
THB9,773.56
(exc. VAT)
THB10,457.71
(inc. VAT)
Tube(s) | Per Tube | Per unit* |
1 - 1 | THB9,773.56 | THB325.785 |
2 - 3 | THB9,558.55 | THB318.618 |
4 + | THB9,353.30 | THB311.777 |
*ตัวบ่งบอกราคา / price indicative |
- RS Stock No.:
- 178-3464
- หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:
- STS1024S05
- ผู้ผลิต / Manufacturer:
- XP Power
ข้อมูลทางเทคนิค / Technical Data Sheets
Legislation and Compliance
- COO (Country of Origin):
- CN
รายละเอียดสินค้า / Product Details
The STS10 is a new series of innovative low cost DC-DC buck regulators. Based on SMD technology and high levels of automation the series offers many features including voltage trimming, remote on/off, continuous short circuit protection, regulation and high efficiency.
Regulated single outputs from 1.2 to 15 VDC
Wide input range
SMD-10 package
Non-isolated
Output voltage trim ±10%
High efficiency up to 96%
Class B conducted & radiated emissions with external components
Short-circuit protection
No heatsink required
Remote On/Off
Tape & reel package available
Short-circuit protection
Full load to +65°C
3 Year Warranty
Wide input range
SMD-10 package
Non-isolated
Output voltage trim ±10%
High efficiency up to 96%
Class B conducted & radiated emissions with external components
Short-circuit protection
No heatsink required
Remote On/Off
Tape & reel package available
Short-circuit protection
Full load to +65°C
3 Year Warranty
For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.
คุณสมบัติ / Specifications
คุณสมบัติ | Value |
---|---|
Output Voltage | 5V dc |
Output Current | 1A |
Input Voltage | 6.5 → 36V dc |
Mounting Type | Surface Mount |
Number of Outputs | 1 |
Package | SMD |
Power Rating | 1W |
Efficiency | 95.5% |
Ripple And Noise | 75mV Pk-Pk |
Maximum Temperature | +105°C |
Minimum Temperature | -40°C |
Series | STS10 |
Line Regulation | ±0.2% |
Protection Features | Short Circuit Protection |
Weight | 1.4g |
Width | 11.8mm |
Maximum Input Current | 900mA |
Depth | 3.6mm |
MTBF | 3.5 (Minimum)Mh |
Load Regulation | ±0.6% |
Length | 15.2mm |
Power Signal Conversion Type | DC-DC |
