XP Power Switching Regulator, Surface Mount, 1.2V dc Output Voltage, 3 → 5.5V dc Input Voltage, 1A Output
- RS Stock No.:
- 178-3460
- หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:
- STS1005S1V2
- ผู้ผลิต / Manufacturer:
- XP Power
สินค้าหมดชั่วคราว (Temporarily out of stock) - จะเป็นแบ๊คออเดอร์จัดส่ง (back order for despatch) 03/10/2024, จัดส่งภายใน (delivery within) 4-6 วันทำการ (working days)
เพิ่ม / Added
ราคา / Price 1 Tube of 30
THB9,722.87
(exc. VAT)
THB10,403.47
(inc. VAT)
| Tube(s) | Per Tube | Per unit* |
| 1 - 1 | THB9,722.87 | THB324.096 |
| 2 - 2 | THB9,423.17 | THB314.106 |
| 3 + | THB9,215.09 | THB307.17 |
| *ตัวบ่งบอกราคา / price indicative | ||
- RS Stock No.:
- 178-3460
- หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:
- STS1005S1V2
- ผู้ผลิต / Manufacturer:
- XP Power
ข้อมูลทางเทคนิค / Technical Data Sheets
Legislation and Compliance
- COO (Country of Origin):
- CN
รายละเอียดสินค้า / Product Details
The STS10 is a new series of innovative low cost DC-DC buck regulators. Based on SMD technology and high levels of automation the series offers many features including voltage trimming, remote on/off, continuous short circuit protection, regulation and high efficiency.
Regulated single outputs from 1.2 to 15 VDC
Wide input range
SMD-10 package
Non-isolated
Output voltage trim ±10%
High efficiency up to 96%
Class B conducted & radiated emissions with external components
Short-circuit protection
No heatsink required
Remote On/Off
Tape & reel package available
Short-circuit protection
Full load to +65°C
3 Year Warranty
Wide input range
SMD-10 package
Non-isolated
Output voltage trim ±10%
High efficiency up to 96%
Class B conducted & radiated emissions with external components
Short-circuit protection
No heatsink required
Remote On/Off
Tape & reel package available
Short-circuit protection
Full load to +65°C
3 Year Warranty
คุณสมบัติ / Specifications
คุณสมบัติ | Value |
|---|---|
| Output Voltage | 1.2V dc |
| Output Current | 1A |
| Input Voltage | 3 → 5.5V dc |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Package | SMD |
| Power Rating | 1W |
| Efficiency | 90.5% |
| Ripple And Noise | 75mV Pk-Pk |
| Maximum Temperature | +105°C |
| Minimum Temperature | -40°C |
| Series | STS10 |
| Line Regulation | ±0.2% |
| Load Regulation | ±0.6% |
| Power Signal Conversion Type | DC-DC |
| MTBF | 3.5 (Minimum)Mh |
| Weight | 1.4g |
| Maximum Input Current | 700mA |
| Protection Features | Short Circuit Protection |
| Depth | 3.6mm |
| Length | 15.2mm |
| Width | 11.8mm |
