- RS Stock No.:
- 124-1570
- หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:
- B-LCDAD-RPI1
- ผู้ผลิต / Manufacturer:
- STMicroelectronics
18 มีของพร้อมจัดส่งภายใน (In stock for delivery within) 4-6 วันทำการ (working days)
เพิ่ม / Added
ราคา / Price Each
THB621.23
(exc. VAT)
THB664.72
(inc. VAT)
Units | Per unit |
1 + | THB621.23 |
- RS Stock No.:
- 124-1570
- หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:
- B-LCDAD-RPI1
- ผู้ผลิต / Manufacturer:
- STMicroelectronics
ข้อมูลทางเทคนิค / Technical Data Sheets
Legislation and Compliance
รายละเอียดสินค้า / Product Details
MIPI DSI Interface TFT LCD Board
The B-LCD40-DSI1 daughterboard is an optional capacitive touchscreen display board that can be used with a Discovery development kit such as the STM32F769I-DISC1. Two interface adapters are also available.
4in TFT LCD touchscreen display panel
Resolution: 480 x 800 pixels (WVGA)
16.7M display colours
RGB vertical stripe of pixel arrangement
MIPI DSI connector
Up to two lanes of MIPI DSI data
Supports single-point touch and gesture or two-point touch
Power supply: +2.8V to +3.3Vdc for both LCD and touch panel, +5V for backlight
For use with ST Discovery Kits 123-1057, 123-1055
Display Interface Adapters
124-1570 B-LCDAD-RPI1 DSI to Raspberry Pi Connector Adapter Board
124-1571 B-LCDAD-HDMI1 DSI to HDMI Connector Adapter Board
Resolution: 480 x 800 pixels (WVGA)
16.7M display colours
RGB vertical stripe of pixel arrangement
MIPI DSI connector
Up to two lanes of MIPI DSI data
Supports single-point touch and gesture or two-point touch
Power supply: +2.8V to +3.3Vdc for both LCD and touch panel, +5V for backlight
For use with ST Discovery Kits 123-1057, 123-1055
Display Interface Adapters
124-1570 B-LCDAD-RPI1 DSI to Raspberry Pi Connector Adapter Board
124-1571 B-LCDAD-HDMI1 DSI to HDMI Connector Adapter Board
คุณสมบัติ / Specifications
คุณสมบัติ | Value |
---|---|
Display Technology | Display Board |
Kit Name | MIPI/DSI to LCD |
