ITW Switches 49-59 Series Push Button Switch, Momentary, Panel Mount, 16mm Cutout, SPDT, Clear LED, 250V ac, IP67
- RS Stock No.:
- 197-7670
- หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:
- 49-59123
- ผู้ผลิต / Manufacturer:
- ITW Switches
- RS Stock No.:
- 197-7670
- หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:
- 49-59123
- ผู้ผลิต / Manufacturer:
- ITW Switches
ข้อมูลทางเทคนิค / Technical Data Sheets
Legislation and Compliance
- COO (Country of Origin):
- BZ
รายละเอียดสินค้า / Product Details
High Current Sealed Pushbuttons
The 49-59 series offers a wide selection of options suitable for use in a wide variety of applications. They are panel sealed to IP67 making them ideal for harsh environments. They have a wide selection of colours, illuminated or non-illuminated options and tabs or insulated leads. They are all panel mounted through a 16mm panel cut out.
Panel mount pushbuttons with rear mounted microswitches that snap into place from the rear after assembly of the actuator
UL94V-Ø rated body and button
Form Z (1 N/O + 1 N/C) contact
Panel sealed to IP67
Max.Panel thickness 1.5 mm
UL94V-Ø rated body and button
Form Z (1 N/O + 1 N/C) contact
Panel sealed to IP67
Max.Panel thickness 1.5 mm
Approvals
UL
คุณสมบัติ / Specifications
คุณสมบัติ | Value |
---|---|
Switch Operation | Momentary |
Illuminated | No |
Panel Cut Out Diameter | 16mm |
Mounting Type | Panel Mount |
Push Button Colour | Green |
Contact Configuration | Single Pole Double Throw (SPDT) |
Voltage Rating | 250V ac |
Push Button Style | Dome |
LED Colour | Clear |
IP Rating | IP67 |
Series | 49-59 |
Contact Current Rating | 10 A @ 250 V ac |
Contact Material | Gold Plated Palladium Nickel |
Contact AC Voltage Rating | 250V |
Manufacturer Part No. | 49-59123 |
Contact DC Voltage Rating | 50V |
Case Colour | Stainless Steel |
Maximum Operating Temperature | +85°C |
Minimum Operating Temperature | -35°C |
Operating Temperature Range | -35 → +85°C |
Terminal Type | Solder |
