Roxburgh EMC, RES1 15A 250 V ac/dc 50 and 60Hz, Chassis Mount RFI Filter, Tab, Single Phase
- RS Stock No.:
- 796-7240
- หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:
- RES1F15
- ผู้ผลิต / Manufacturer:
- Roxburgh EMC
ขออภัย เราไม่สามารถตรวจสอบสต็อคสินค้าได้ในเวลานี้ โปรดรีเฟรชเพจอีกครั้ง
เพิ่ม / Added
ราคา / Price Each
THB1,502.94
(exc. VAT)
THB1,608.15
(inc. VAT)
| Units | Per unit |
| 1 - 9 | THB1,502.94 |
| 10 - 24 | THB1,472.88 |
| 25 - 49 | THB1,443.43 |
| 50 - 99 | THB1,414.56 |
| 100 + | THB1,386.27 |
- RS Stock No.:
- 796-7240
- หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:
- RES1F15
- ผู้ผลิต / Manufacturer:
- Roxburgh EMC
ข้อมูลทางเทคนิค / Technical Data Sheets
Legislation and Compliance
- COO (Country of Origin):
- KR
รายละเอียดสินค้า / Product Details
Roxburgh RES1 Series
Compact Single stage Chassis mount EMI/EMC filter
Featuring metal case and screw terminals
Epoxy molded for reliability
Significant differential mode performance Suitable for industrial machinery
Low input leakage current makes it suitable for portable equipment
Featuring metal case and screw terminals
Epoxy molded for reliability
Significant differential mode performance Suitable for industrial machinery
Low input leakage current makes it suitable for portable equipment
คุณสมบัติ / Specifications
คุณสมบัติ | Value |
|---|---|
| Maximum Current Rating | 15A |
| Maximum Voltage Rating | 250 V ac/dc |
| Mounting Type | Chassis Mount |
| Termination Style | Tab |
| Number of Phases | 1 |
| Series | RES1 |
| Number of Stages | Single Stage |
| Operating Frequency | 50 and 60Hz |
| Length | 83.5mm |
| Depth | 38mm |
| Height | 51.8mm |
| Dimensions | 83.5 x 38 x 51.8mm |
| Leakage Current | >0.5 mA |
| Minimum Operating Temperature | -25°C |
| Maximum Operating Temperature | +85°C |
| Standards Met | EN 60950, UL 1283 |
