RS PRO 12V ac 2 Output Through Hole PCB Transformer, 20VA
- RS Stock No.:
- 504-684
- ผู้ผลิต / Manufacturer:
- RS PRO
38 มีของพร้อมจัดส่งภายใน (In stock for delivery within) 4-6 วันทำการ (working days)
เพิ่ม / Added
ราคา / Price Each
THB1,741.20
(exc. VAT)
THB1,863.08
(inc. VAT)
| Units | Per unit |
| 1 - 9 | THB1,741.20 |
| 10 - 24 | THB1,671.58 |
| 25 - 49 | THB1,601.93 |
| 50 + | THB1,567.09 |
- RS Stock No.:
- 504-684
- ผู้ผลิต / Manufacturer:
- RS PRO
ข้อมูลทางเทคนิค / Technical Data Sheets
Legislation and Compliance
- COO (Country of Origin):
- PL
รายละเอียดสินค้า / Product Details
PCB Mounting, Flame Retardant Transformer with Thermal Fuse
Thermal fuse in primary providing overload and short circuit protectionFlame retardant materials to UL94-V0Fully shrouded windingsExtra pins for secure board mountingDesigned and tested in accordance with EN 61558 (EN 60742) EN 60950
Approvals
8888
Standards
EN 61558 (EN 60742); EN 60950
Open Frame - Laminated
PCB mounting mains transformers with a single 230Va.c. or twin 115Va.c. 50/60Hz primary winding. Independent secondary windings may be connected in series or parallel to give a wide range of output voltage and current options.
Double section metric bobbin constructionFull varnish impregnation
คุณสมบัติ / Specifications
คุณสมบัติ | Value |
|---|---|
| Secondary Voltage Rating | 12V ac |
| Power Rating | 20VA |
| Primary Voltage Rating | 230V ac |
| Number of Outputs | 2 |
| Length | 60mm |
| Width | 54mm |
| Depth | 42mm |
| Dimensions | 60 x 54 x 42mm |
| Weight | 500g |
| Mounting Type | Through Hole |
| Minimum Operating Frequency | 50Hz |
| Maximum Operating Frequency | 60Hz |
