Keysight Technologies DSOX2004A InfiniiVision 2000 X Series Digital Bench Oscilloscope, 4 Analogue Channels, 70MHz
- RS Stock No.:
- 725-0498
- หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:
- DSOX2004A
- ผู้ผลิต / Manufacturer:
- Keysight Technologies
7 มีของพร้อมจัดส่งจากคลังสินค้าทั่วโลก (Global stock) ภายใน (Within) 4-6 วันทำการ (working days)
1 มีของพร้อมจัดส่งจากคลังสินค้าทั่วโลก (Global stock) ภายใน (Within) 4-6 วันทำการ (working days)
ราคา / Price Each
THB116,062.25
(exc. VAT)
THB124,186.61
(inc. VAT)
Units | Per unit |
1 - 4 | THB116,062.25 |
5 + | THB113,741.00 |
- RS Stock No.:
- 725-0498
- หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:
- DSOX2004A
- ผู้ผลิต / Manufacturer:
- Keysight Technologies
ข้อมูลทางเทคนิค / Technical Data Sheets
Legislation and Compliance
สถานะRoHS: ได้รับการยกเว้น
- COO (Country of Origin):
- MY
รายละเอียดสินค้า / Product Details
Keysight Technologies Oscilloscope, 1GSa/s Sample Rate, 70MHz Bandwidth - InfiniiVision 2000 X Series - DSOX2004A
For trouble-free reading of electrical signals, turn to this oscilloscope from Keysight Technologies. Its four analogue inputs can connect to a signal source, sending an easy-to-read waveform graph to its WVGA screen. This handy setup lets you breeze through measurements such as time, frequency and amplitude for comprehensive analysis. Thanks to its generous bandwidth of 70MHz, this device will accurately show high-frequency waveforms. This unit has a wide operating temperature range of 0°C to +50°C, so it'll beat the heat in harsh industrial settings.
Features & Benefits
Rapid update rate of 200,000 waveforms per second for seeing your signal in greater detail
Screen size of 8.5in for good visibility of results
Optional CAN, LIN, I²C, SPI and RS232/UART protocols for performing serial analysis
Maximum memory of 1Mpts for capturing more signal data
Screen size of 8.5in for good visibility of results
Optional CAN, LIN, I²C, SPI and RS232/UART protocols for performing serial analysis
Maximum memory of 1Mpts for capturing more signal data
Applications
Medical facilities
Manufacturing industry
Automotive maintenance
Consumer technology servicing
Manufacturing industry
Automotive maintenance
Consumer technology servicing
What's the rise time of this unit?
The maximum rise time of this oscilloscope is just 5ns, so it will be up and running in no time flat.
คุณสมบัติ / Specifications
คุณสมบัติ | Value |
---|---|
Digital/Analogue | Digital |
Number of Analogue Channels | 4 |
Bandwidth | 70MHz |
Oscilloscope Type | Bench |
Oscilloscope Form | Digital Storage |
Series | InfiniiVision 2000 X |
Power Source | Mains |
Interface | USB |
Display Type | Colour |
Memory Depth | 100kpts |
Waveform Refresh Rate | 200000per sec |
Minimum Vertical Sensitivity | 1mV/div |
Maximum Vertical Sensitivity | 5V/div |
Minimum Time Base | 5ns/div |
Screen Size | 8.5in |
Sample Rate Random | 2 Gsps |
Record Length | 50k points/ch |
Input Impedance | 1 MO |
Vertical Resolution | 8 bit |
Dimensions | 380.6 x 141.5 x 204.4mm |
Maximum Time Base | 50s/div |
Weight | 3.9kg |
Plug Type | Type C - European Plug, Type G - British 3-pin |
Safety Category | CAT I 300 V, CAT II 300V |
Rise Time | = 5ns |
