STMicroelectronics STM32F446RET6, 32bit ARM Cortex M4 MCU, 180MHz, 512 kB Flash, 64-Pin LQFP

  • RS Stock No. 110-6621
  • หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No. STM32F446RET6
  • ผู้ผลิต / Manufacturer STMicroelectronics
ข้อมูลทางเทคนิค / Technical Data Sheets
Legislation and Compliance
RoHS Certificate of Compliance
รายละเอียดสินค้า / Product Details

STM32F446 Microcontrollers, STMicroelectronics

The STM32F446 enables high performance and rich connectivity into a highly integrated and energy efficient microcontroller. It is based on the ART Accelerator, smart architecture, advanced Flash technology and its embedded ARM Cortex-M4 core. The microcontroller can achieve leading performance up to 225 DMIPS and 608 CoreMark at 180 MHz, executing from embedded Flash.

STM32F4 Series 32-Bit ARM Cortex-M4 Microcontrollers, STMicroelectronics

The ARM Cortex-M4 based STM32 F4 series of high-performance MCUs with DSP and FPU instructions is an extension of the industry-leading STM32 portfolio towards even higher performance. Up to 180 MHz operating frequency.

Up to 2x USB 2.0 OTG FS/HS
SDIO (Secure Digital Input Output)
USART, SPI, I²C
I²S (Inter-IC Sound) + Audio PLL
16 and 32 Bit Timers
Up to 3x 12-Bit ADC
Low Voltage 1.7 V to 3.6 V

คุณสมบัติ / Specifications
คุณสมบัติ Value
Family Name STM32
Package Type LQFP
Mounting Type Surface Mount
Pin Count 64
Device Core ARM Cortex M4
Data Bus Width 32bit
Program Memory Size 512 kB
Maximum Frequency 180MHz
RAM Size 128 kB
USB Channels 2
ADC Channels 16
Typical Operating Supply Voltage 1.8 → 3.6 V
ADC Resolution 12bit
Number of Timers 12
Number of ADC Units 3
ADCs 3 (16 x 12 bit)
Width 10mm
Timer Resolution 16 bit, 32 bit
Timers 2 x 32 bit, 12 x 16 bit
Program Memory Type Flash
Data Rate 45Mbps
Maximum Operating Temperature +85 °C
Length 10mm
Dimensions 10 x 10 x 1.45mm
Minimum Operating Temperature -40 °C
Height 1.45mm
Instruction Set Architecture RISC
138 มีของพร้อมจัดส่งภายใน (In stock for delivery within) 5 - 8 วันทำการ (working days)
ราคา / Price Each
THB 227.53
(exc. VAT)
THB 243.46
(inc. VAT)
Units
Per unit
1 - 4
THB227.53
5 - 9
THB222.54
10 - 99
THB219.47
100 - 499
THB200.15
500 +
THB186.40
