STMicroelectronics STM32F070CBT6, 32bit ARM Cortex M0 Microcontroller, 48MHz, 128 kB Flash, 48-Pin LQFP

  • RS Stock No. 110-6133
  • หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No. STM32F070CBT6
  • ผู้ผลิต / Manufacturer STMicroelectronics
ข้อมูลทางเทคนิค / Technical Data Sheets
Legislation and Compliance
RoHS Certificate of Compliance
รายละเอียดสินค้า / Product Details

STM32F07 Series Microcontrollers, STMicroelectronics

RISC Core: ARM 32-bit Cortex-M0 CPU, frequency up to 48MHz
CRC calculation unit
Power management
Clock management
Up to 86 fast Inputs/Outputs
7-channel DMA controller
12 Timers
Communication interfaces: I2C, USART, SPI, CAN, USB 2.0 full-speed

STM32F0 Series 32-Bit ARM® Cortex®-M0 Microcontrollers, STMicroelectronics

The STM32 F0 Series of the 32-bit Flash Microcontrollers (MCUs) is based on the ARM Cortex™-M0 core; a core specifically developed for embedded applications. STMicroelectronics’s STM32 ARM Cortex™ M processor benefits from the Cortex-M0 architectural enhancements including digital signal processing, real-time performance, low voltage and low power. ST’s ARM® STM32 F0 mainstream series delivers a 32-bit performance and is ideal for small projects or platform decisions with its easy to use functionality.

คุณสมบัติ / Specifications
คุณสมบัติ Value
Family Name STM32
Package Type LQFP
Mounting Type Surface Mount
Pin Count 48
Device Core ARM Cortex M0
Data Bus Width 32bit
Program Memory Size 128 kB
Maximum Frequency 48MHz
RAM Size 16 kB
USB Channels 1
ADC Channels 13
Typical Operating Supply Voltage 2.4 → 3.6 V
Number of Timers 5
ADCs 1 (13 x 12 bit)
Number of ADC Units 1
Width 7.2mm
ADC Resolution 12bit
Timer Resolution 16bit
Timers 5 x 16 bit
Minimum Operating Temperature -40 °C
Instruction Set Architecture RISC
Program Memory Type Flash
Dimensions 7.2 x 7.2 x 1.45mm
Length 7.2mm
Maximum Operating Temperature +85 °C
Data Rate 18Mbps
Height 1.45mm
90 มีของพร้อมจัดส่งภายใน (In stock for delivery within) 5 - 8 วันทำการ (working days)
ราคา / Price Each: (In a Pack of 5)
THB 75.458
(exc. VAT)
THB 80.74
(inc. VAT)
Units
Per unit
Per Pack*
5 - 5
THB75.458
THB377.29
10 - 95
THB71.38
THB356.90
100 - 495
THB62.236
THB311.18
500 - 1495
THB59.008
THB295.04
1500 +
THB56.692
THB283.46
*ตัวบ่งบอกราคา / price indicative
