RS PRO 200VA 2 Output Chassis Mounting Transformer, 6V ac

  • RS Stock No. 504-098
  • ผู้ผลิต / Manufacturer RS PRO
ข้อมูลทางเทคนิค / Technical Data Sheets
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): PL
รายละเอียดสินค้า / Product Details

Chassis Mount Frame 75VA to 200VA

The two independent secondary windings may be connected in series or parallel to give a wide range of output voltage and current options.

Optional terminal shrouds for 75VA and 100VA

Approvals

8888

Standards

BS3535; EN 60 742

Laminated Frame 230Vac Primary 75VA to 200VA (Multi Tapped)

Chassis mounting frame construction low voltage mains transformers with a single 230Vac 50/60Hz primary winding.

Double section bobbin construction
Fully shrouded bobbins
Full varnish impregnation
Multi-hole frame fixing
Solder tag terminations
100% electrical and flash tested
Tested in accordance with BS3535 and EN 60 742

คุณสมบัติ / Specifications
คุณสมบัติ Value
Primary Voltage Rating 230V ac
Secondary Voltage Rating 6V ac
Power Rating 200VA
Number of Outputs 2
Mounting Type Chassis
Length 100mm
Width 92mm
Depth 82mm
Dimensions 100 x 92 x 82mm
Fixing Hole Diameter 5.5 x 8.5mm
Weight 2.8kg
Minimum Operating Frequency 50Hz
Maximum Operating Frequency 60Hz
10 มีของพร้อมจัดส่งภายใน (In stock for delivery within) 5 - 8 วันทำการ (working days)
ราคา / Price Each
THB 1,705.72
(exc. VAT)
THB 1,825.12
(inc. VAT)
Units
Per unit
1 - 9
THB1,705.72
10 - 24
THB1,461.14
25 - 49
THB1,350.89
50 - 99
THB1,252.55
100 +
THB1,168.91
