RS PRO 200VA 2 Output Chassis Mounting Transformer, 15V ac
- RS Stock No.:
- 503-934
- ผู้ผลิต / Manufacturer:
- RS PRO
16 มีของพร้อมจัดส่งภายใน (In stock for delivery within) 4-6 วันทำการ (working days)
เพิ่ม / Added
ราคา / Price Each
THB4,850.56
(exc. VAT)
THB5,190.10
(inc. VAT)
| Units | Per unit |
| 1 - 9 | THB4,850.56 |
| 10 - 19 | THB4,753.55 |
| 20 + | THB4,658.44 |
- RS Stock No.:
- 503-934
- ผู้ผลิต / Manufacturer:
- RS PRO
ข้อมูลทางเทคนิค / Technical Data Sheets
Legislation and Compliance
- COO (Country of Origin):
- PL
รายละเอียดสินค้า / Product Details
Chassis Mount Frame 75VA to 200VA
The two independent secondary windings may be connected in series or parallel to give a wide range of output voltage and current options.
Optional terminal shrouds for 75VA and 100VA
Chassis Mount Frame 75VA to 200VA
The two independent secondary windings may be connected in series or parallel to give a wide range of output voltage and current options.
Optional terminal shrouds for 75VA and 100VA(503-928)
The two independent secondary windings may be connected in series or parallel to give a wide range of output voltage and current options.
Optional terminal shrouds for 75VA and 100VA(503-928)
Approvals
8888
Standards
BS3535; EN 60 742
คุณสมบัติ / Specifications
คุณสมบัติ | Value |
|---|---|
| Primary Voltage Rating | 230V ac |
| Secondary Voltage Rating | 15V ac |
| Power Rating | 200VA |
| Number of Outputs | 2 |
| Mounting Type | Chassis |
| Length | 100mm |
| Width | 92mm |
| Depth | 82mm |
| Dimensions | 100 x 92 x 82mm |
| Fixing Hole Diameter | 5.5 x 8.5mm |
| Weight | 2.8kg |
| Minimum Operating Frequency | 50Hz |
| Maximum Operating Frequency | 60Hz |
